3L internal mixer_a
2 year ago
Guangdong 3L Small Internal Mixer High Temperature Internal Mixer Laboratory Small Internal Mixer Plastic Internal Mixer
2. Main motor: AC motor with a power of 7.5 kW
3. Reducer: The base and frame are made of low-carbon steel structure, with a forced lubrication circulation system;
4. Control mode: manual or semi-automatic operation; Mixer temperature: tap water - room temperature -300 ° C is the standard temperature. I have done it before, reaching a temperature of 650 ° C
Mechanical body
5. The base frame is welded with profile steel and steel plates, and processed into
6. The middle groove of the mixing chamber is made of wear-resistant alloy steel and the side wall is welded with medium carbon steel plate and processed
7. Alloy steel is used for the axis and blades of the mixing shaft
8. The anti leakage device adopts a mechanical shaft seal at the side end of the mixing shaft for tightening, and the anti leakage structure has been awarded a certificate
Pressure cap device
9. The pressure cap is made of alloy steel, and pressure is applied to the raw materials during the mixing operation. The air cylinder is used for vertical lifting and lowering movements
Unloading device
10. Tilting angle 110 °~135 °
11. Tilting power: hydraulic tipping bucket
The core concept of Zhenggong Technology:
Adhere to integrity, mutual benefit, and common prosperity, and carry things with great virtue.
The quality concept of Zhenggong Technology:
Quality first, reputation first, management first, and service sincere.
21. The main motor has a 7.5KW AC voltage of 440V, 415V, 380V, 220V, and 110V, which can be selected according to customer needs
22. Transmission method: The main motor and reducer are connected for transmission
Piping
23. Air pressure piping, compressed air accessories (three-point combination, solenoid valve), and mechanical body piping
Main electrical control equipment
24. Temperature setting: both automatic and manual
25. With prompt actions and various time settings, it can achieve forward and reverse rotation
Advantages of Machine
26. The main electrical components are imported brands, and the bearings of the entire machine use the Timken TWB brand
27. The stirring shaft is made of alloy steel. Easy to wear parts are welded with wear-resistant front steel imported from West Germany, which is more secure and durable
28. The mixed groove is of the "mountain" shape, and the main body of the mixed groove is made of wear-resistant alloy steel for overall processing. The shear part is welded with West German Feng steel
29. The side wall leak proof device adopts high-tech materials: the leak proof structure has been awarded a certificate
30. The pressure cap adopts an "M" shaped structure, making the mixing of rubber materials more uniform
31. Volume: (W × D × H) 1550 * 850 * 1980MM
32. Weight: 1880KG
Small internal mixer: 0.05L0.1L0.2L0.3L0.5L1L2L3L5L8L10L15L20L25L35L Internal mixer desktop, pressurized, flipped, open close, clutch, closed, electrically heated water cooled laboratory internal mixer, vacuum internal mixer, metal ceramic powder internal mixer, internal mixer granulator integrated machine
Small internal mixer: 0.05L0.1L0.2L0.3L0.5L1L2L3L5L8L10L15L20L25L35L Internal mixer desktop, pressurized, flipped, open close, clutch, closed, electrically heated water cooled laboratory internal mixer, vacuum internal mixer, metal ceramic powder internal mixer, internal mixer granulator integrated machine
Small tablet press: 5T10T20T25T30T50T65T100T150T200T300T single layer, double layer, four column, with safety door, upper layer heating and lower layer water cooling, one layer electric heating and water cooling integrated, electric heating, water cooling, oil heating, hydraulic system, manual, semi-automatic, pneumatic, fully automatic laboratory small tablet press, hot pressing molding machine, rubber and plastic molding machine.
Small vulcanizing machine: 5T10T20T25T30T50T65T100T150T200T single layer, double layer, four column, with safety door, electric heating, water cooling, oil heating, hydraulic system, pneumatic, manual, semi-automatic, fully automatic flat vulcanizing machine, vacuum vulcanizing machine.
