Automatic easy open end making machine
Our company is mainly engaged in tin can production line, easy open end production line and canned fish processing line.
We provide the following series processing lines:
♠ Canned Fish Processing Line
(Canned tuna processing line, canned sardine processing line, canned Mackeral line,Tilapia, Nile Perch Processing Lines, etc.)
♣ Tin can production Line
(2-piece & 3-piece tin can,fancy tin can, paint tin can,etc)
♥ Easy open end production line
(Tin EOE & Alu. EOE)
♦ Twist off cap making line
(Twist off and SKO)
The processing lines include the equipments from raw materials to finished canned products, packing and warehousing. Together with tin can making line, we can provide A-Z productions lines for customers.
Main technical parameters:
|
Name |
Automatic Easy Open End (EOE) Making Line |
|
Model |
1#/2# |
|
Usage |
It's used for punching basic lid of easy open end |
|
Nominal Pressure |
60T / 120T |
|
Slide Block Stroke |
105mm / 120mm |
|
Stroke |
Max.200 strokes/min (Ø52-99mm); Max.150 strokes/min (Ø99-153mm) |
|
Max. Die Number on 60T |
Max. 2 dies (Ø52-99mm) & 1 die (Ø99-153mm) |
| Max. Die Number | Max. 7 dies (Ø52-99mm) & 2 dies (Ø99-153mm) |
| Power | 25KW / 35KW |
| Dimension | 4500*2800*3000mm / 5500*3200*3200mm |
|
Weight |
6.5T / 12T |
Installation in Customer's Factory
