High Voltage Diode 2CL08K

6 month ago

11 0 

YANGZHOU POSITIONING TECH CO., LTD.

7 year

Product details

Plastic Fast Recover High Voltage Rectifier

YZPST-2CL08K

Reverse Voltage 8kV

Forward Current 5mA

Features

For high resolution displays or TV receivers and Working automation equipment
Diffused-junction
Excellent high temperation output characteristics (Small leakage current at high temperature and excellent reverse characterics)

YZPST-2CL08K
Maximum Ratings & Thermal Characteristics Ratings at 25℃ ambient temperature unless otherwise specified.

ltem	Symbols	2CL06K	Unit
Repetitive Peak Reverse Voltage	VRRM	8	KV
Average Forward Current	IF(AV)	5 (50HZ half-sine wave,Resistance load Ta=25℃)	mA
Average Forward Current	IF(AV)	5 (50HZ half-sine wave,Resistance load Ta=25℃)	mA
Non-Repetitive Forward Surge Current	IFSM	2 (50HZ half-sine wave,1/2 cycle, Ta=25℃)	A
Ambient temperature	Tamb	-40 --- +100	℃
Virtual Junction Temperature	TJ	120	℃
Storage temperature	Tstg	-40 --- +120	℃

Electrical Characteristics Ratings at 25℃ ambient temperature unless otherwise specified.

ltem			Symbols	2CL08K	Unit
Forward voltage Drop		IF = 10mA	VF	10	V
Normal Temperature Reverse Current		VR=VRRM	IRm1	2	μA
TA=100℃ High Temperature Reverse Current		VR=VRRM	IRm2	5	μA
Reverse Recovery Time	IF=2mA , Irp=4mA 1mA recovery		trr	100	nS
