Ceramic gasket
2 year ago
Customized alumina ceramic gaskets
Alumina ceramic gaskets can be customized to meet specific requirements for various applications. Some of the customization options for alumina ceramic gaskets include:
1. Size and shape: Alumina ceramic gaskets can be customized to specific dimensions and shapes to fit the requirements of the equipment or machinery they are intended for.
2. Thickness: The thickness of alumina ceramic gaskets can be customized to provide the required level of sealing and insulation for different applications.
3. Surface finish: The surface finish of alumina ceramic gaskets can be customized to meet specific sealing and insulation requirements, such as smooth or textured surfaces.
4. Tolerance and precision: Alumina ceramic gaskets can be customized to meet specific tolerance and precision ceramics requirements to ensure a perfect fit and sealing performance.
5. Material composition: The material composition of alumina ceramic gaskets can be customized to include additives or reinforcements to enhance specific properties, such as thermal conductivity,Electrical Ceramics insulation, or chemical resistance.
6. Customized features: Alumina ceramic gaskets can be customized with additional features, such as grooves, holes, or special designs, to meet specific application requirements.
Overall, the customization of Al2O3 Ceramics gaskets allows for tailored solutions to meet the unique needs of different industries and applications.
Technical Parameters:
| Item | Unit | Al2O3 95％－97％ | Al2O3 99％ |
| Desity | g/cm3 | 3.7 | 3.85 |
| Flexural Strength | Mpa | 300 | 340 |
| Compressive Strength | Mpa | 3400 | 3600 |
| Modulus of Elaslicity | Gpa | 350 | 380 |
| Impact Resistance | Mpa m1/2 | 4.0 | 5 |
| Weibull Moudulus | m | 10.0 | 10 |
| Vickers Hardness | HV0.5 | 1200.0 | 1300 |
| Thermal Expansion Coefficent | 10-6K-1 | 5.0-8.3 | 5.4-8.3 |
| Thermal Conductivity | W/mK | 24 | 27 |
| Thermal Shork Resistance | △T℃ | 250 | 270 |
| Maximum Use Temperature | ℃ | 1600 | 1650 |
| Volume Resistivity at 20℃ | Ω | ≥1014 | ≥1014 |
| Dielectric Constant | KV/mm | 20 | 25 |
| Open Porosity | % | 0 | 0 |
| Dielectric Constant | ξr | 10 | 10 |
| Dielectric Loss Angle | Tanσ | 0.001 | 0.001 |
| Item | Unit | ZrO2 | ZTA |
| Desity | g/cm3 | 6.05 | 4.1 |
| Flexural Strength | Mpa | 1300 | 480 |
| Compressive Strength | Mpa | 3000 | 3300 |
| Modulus of Elaslicity | Gpa | 205 | 320 |
| Impact Resistance | Mpa m1/2 | 12 | 7 |
| Weibull Moudulus | m | 25 | 15 |
| Vickers Hardness | HV0.5 | 1150 | 1600 |
| Thermal Expansion Coefficent | 10-6K-1 | 10 | 9 |
| Thermal Conductivity | W/mK | 2 | 20 |
| Thermal Shork Resistance | △T℃ | 280 | 260 |
| Max Useage Temperature | ℃ | 1000 | 1600 |
| Volume Resistivity at 20℃ | Ω | ≥1010 | ≥1012 |
| Open Porosity | % | 0 | 0 |
Except for the engineering ceramics , we have many other advanced ceramic parts, like ceramic substrates, ceramic plunger ,ceramic disc,ceramic tubes,ceramic rod,ceramic sealing piston ,ceramic grinders, ceramic guides and so on.
