2W025-06S brass solenoid valve
2 year ago
2W025-06s 2/2 Way Water Solenoid Valve 24V
Product introduction
2W025-06S water solenoid valve is constructed with brass body, orifice size: 2.5mm, port size: 1/8". The general operation mode is normally closed direct acting type, and its sealing materials include NBR, EPDM, VITON can be applied to a variety of working media. As one of the typical hydraulic control solenoid valves, it can be perfectly used in industrial and domestic hydraulic control systems, such as garden farm irrigation systems.
Brass valve body
The body of 2W025-06S is made of solid brass and has a thick wall for longer service life. The smooth thread of fine machining ensures continunous operation is not easily damged, making it safer and more reliable.
Stable Solenoid coil
The stable coil enables good heat dissipation, good insulation performance. The surface shell clearly and comprehensively display the specific parameters of the water valve.
Wide application
It can be used for both industrial use and household use, such as air control, liquid control, irrigation control, water filtration and treatment, etc.
Pay Attention:
◆ Please check whether the product is intact before use
◆ Please confirm that the installation conditions are in accordance with the specifications
◆ Please use in a stable environment
◆ Pay attention to clean up dust and other things that affect operation
Main technical parameters
|
Specification |
|||||||||||||
|
Model |
2W025-06S |
2W025-08S |
2W030-08S |
2W040-10S |
2WH012-06S |
2WH012-08S |
2W020-10S |
||||||
|
Working Medium |
Air, Water, Oil, Gas |
||||||||||||
|
Operation |
Direct Acting, 2/2 Way |
||||||||||||
|
Acting Type |
Normal Closed Type |
||||||||||||
|
Port Size |
1/8'' |
1/4'' |
1/4'' |
3/8'' |
1/8'' |
1/4'' |
3/8'' |
||||||
|
Material |
Brass |
||||||||||||
|
Working Pressure |
Air, Water, Oil, Gas: 0~1.0Mpa; Air, Water, Oil: 0~2.0Mpa |
||||||||||||
|
Orifice Size |
2.5 |
3 |
4 |
1.2 |
1.2 |
2 |
|||||||
|
CV Value |
0.23 |
0.23 |
0.33 |
0.60 |
0.05 |
0.05 |
0.15 |
||||||
|
Voltage |
DC12V, DC24V, AC24V, AC110V, AC220V, AC380V |
||||||||||||
|
Fluid Viscosity |
20 CST Below |
||||||||||||
|
Voltage Range |
±10% |
||||||||||||
|
Material sealing |
NBR, EPDM, VITON |
||||||||||||
|
Operation Temperature |
NBR: -5~80℃, EPDM: -5~120℃, VITON: -10~150℃, SI: -15~150℃ |
||||||||||||
2W025-06S Dimension
