Chnki Sewing Machine H360 Series To Make Hip Pads

The H360 is driven by double screws and double closed-loop motors, which is different from the traditional crawler, the double screws are more durable and increase the service life of the machine, the H360 is cast in one piece of the body, which ensures the stability of the machine when sewing at high speeds, and the H360 has the FRID template recognition system, which can quickly recognize the patterns and improve the efficiency.

    Flexible Intermediate Presser foot driving system, reduce the amount of down off-tracking, when users sew down products, and effectively reduce production costs. Improve products quality. It can be programmed according to different fabric thicknesses, The height of the press foot can match to different duty, improve the stitch quality.

Advantage:

1、Keep forward stitch

2、High speed angle sewing

3、Better solution for special-shaped pattern

4、Short head rotation radius

5、Oversize of sewing area. 900mm*1300mm; Customized size: 900mm*1500mm

6、Chnki flexible & programmable intermediate presser foot

7、Stepping motor drive double screw rod & double close loop

8、One piece casting of body and base

9、Top thread breakage detection

10、Compliance with 7-8# needle

11、2 times bobbin thread capacity system

12、Round knife cutting system

13、Dry head design

14、7 inch LCD touch panel

15、Adjustable template groove design.

Optional device:

1、Laser cutting device

2、Laser glavo device

3、IOT function

4、Chalk function

5、Double template feeding device

6、Template fixed clasp device

7、Automatic bobbin change
