JS concrete mixer
3 year ago
Conjoined JS500 concrete mixer is a kind of high efficient concrete mixing equipment, which consists of a conjoined frame and two JS500 forced concrete mixers. The discharges of these two mixers are connected together and use the same batching machine. This mixer is capable of mixing many types of concrete and mortar, including dry hard concrete, plastic concrete, flowing concrete, and light aggregate concrete.
The conjoined JS500 concrete cement mixer has several advantages.
First of all, it can work alone or with PLD series batching machine to form a simple concrete batching plant. This double advantage makes the mixer more flexible and can be adapted to different project needs.
Secondly, the conjoined JS500 concrete cement mixer adopts the forced mixing method, which can ensure the uniform mixing of concrete. The mixer is equipped with efficient mixing blades and mixing tank, which can mix the concrete fully and evenly and ensure the quality of concrete.
Parameters
Model
JS500
Discharge capacity(L)
500
Drum capacity(L)
800
Productivity(m3/h)
≥25
Max.aggregate diameter(mm)
≤60/80
Working cycle time(s)
72
Total weight(kg)
4000
Outline dimension(mm)
Transporting
3050×2530×2680
Operating
4461×3050×4180
Mixing Blade
Rotational speed
(r/min)
35
Count
2×7
Mixing Motor
Model
Y180M–4
Power(KW)
18.5
Pump motor
Model
BL12-12-1.1
Power(KW)
1.1
Discharging Height(mm)
3800
