CANGHAI cangzhou dongguang corrugated board cartoon box making machine
1. Raw material: waste paper
2. Output paper: brown craft paper and white craft liner paper
3. Capacity: 200 ton/day
4. Net paper width: 4800 mm
5. Paper grammage: 90-180 g/m²
6. Wire width: 5200 mm
7. Bearing center-center: 5700 mm
8. Design speed: 250 m/min
9. Working speed: 180-220 m/min
10. Drive way: Alternating current frequency conversion, speed regulation, section drive.
|
Model number |
Working speed (m/min) |
Type of corrugation |
Way of heating |
|
1400-1800 |
100 |
A C B D E F |
Electric/steam/gas |
Technical parameters:
1. Fourdrinier section: open type headbox 3 sets, lip plate made of stainless steel, upper lip plate can be used for full-size and local regulation, mouth spray width 5200mm. Ceramic dewatering elements with vacuum water suction boxes. 21m+8m+8m fourdrinier table. Φ650mm breast roll, Φ700mm drive net roll, Φ850mm vacuum couch roll.fourdrinier section machine frame is welded steel, couch roll up and down by air cylinder regulation, equipped with air control box.
2. Press section: first press section: Φ800mm marble roll 1set, Φ800mm vacuum stainless steel roll 1set, Φ800mm rubber roll 1set; second press section: press with large diameter roll, Φ1250mm marble roll 1set, Φ1250mm rubber roll 1set.electric tightener. Frame is welded steel.
3. Dryer cylinder section: Φ1800mm dryer cyliner 32pcs (20+sizing machine+12). Frame is made of cast iron and steel with tempering treatment.scraper with high density EP blade. Electric tightener. Open type exhaust hood.
4. Sizing machine: Φ710mm upper roll 1set, Φ705mm lower roll 1set, all coated by rubber. Upper roller with pneumatic scraper device for paper carrying or cleaning when machines stop. Weled steel structure frame.
5. Calendar section: Φ610mm/Φ610mm pneumatic type double roller calendar 1set.
6. Winding part: horizontal type winding machine 1set, Φ1100mm cylinder.
7. Compressed air system and hydralic control system: hydralic station and high pressure cylinder.
8. Central lubrication system: lubracation oil station, distributor and joint.
9. Drive part: frequency conversion control system, Alternating frequency motor, hardened surface reducer and driven accessories/attachment.
