Raycus JPT 50w metal fiber laser engraver name plate jewelry engraving and cutting machine/30 watt fiber laser marking1

2 year ago
12 0
Product details
Product Description
Description
Parameters
Laser Source
Max
Laser Power
20W:18-19W; 30W:25W
Wavelength
1064±4nm
Beam Quality
M<1.2
Repetition Frequency
27.7Khz-62.5KHz
Pulse Width
80-100ns
Marking Area
110/140/170/200 mm optional
Marking Depth
<2mm
Min Character Size
0.05mm
Repeatability accuracy
±0.01mm
Cooling System
Air Cooling
Power Consumption
<1000W
Min Line Width
0.01mm
Product Size & Weight
300*450*650mm,20KG
Packing Size & Weight
800*450*390mm,22KG
Marking Speed
0~400m/minute
Working Power
AC220V/50(60)Hz, AC110V/50(60)Hz etc., as per request
Power Plug
Euro, American, SANS etc., as per request
Specification
item
value
Application
Laser Marking
Working Accuracy
0.01mm
Graphic Format Supported
AI, BMP, Dst, Dwg, DXF, LAS, PLT, JPG, CAD, CDR, DWG,PCX
Laser Type
Fiber Laser
Condition
New
CNC or Not
Yes
Cooling Mode
Air Cooling
Control Software
EZCAD
Place of Origin
SHANDONG CHINA
Brand Name
ZHONGDE
Laser Source Brand
RAYCUS
Weight (KG)
50KG
Key Selling Points
High Productivity
Warranty
2 years
Applicable Industries
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Marking Area
500mm*500mm
Machinery Test Report
Provided
Video outgoing-inspection
Provided
Warranty of core components
2 years
Core Components
Pressure vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine, PLC
Mode of Operation
Pulsed
Configuration
bench-top
Feature
Air-cooled
Product name
Lazer Marking Machine
Laser Power
20W /30w/ 50w(Optional)
Laser source
IPG Raycus Max JPT
Keywords
20w30w50w Laser Marking Machine
Function
Marking Logo Metal Non Metal
Power
AC 220V/50~60HZ
Type
Fbier Laser
Applicable Material
Metal Materials
Marking material
SS CS Aluminum Metal Plastic
Machine type
Mini Portable Laser Marker
Packing & Delivery
Fumigation-free wooden box. Not include shipping costs.
Company Profile
Shandong Zhongde Machine Tool Accessories Co., Ltd. was established on March 4, 2004. Professional R&D and manufacturing for 18 years: machine chip conveyor, cable drag chain, cantilever control box, machine tool damping foot. We mainly serve the European market and the Asian market, and our products are sold in 39 countries. With our sincere corporate culture, we are deeply loved and praised by our customers. Established in 2004, Shandong Zhongde Machine Tool Accessories Producing Co., Ltd. is a professional manufacturer of Cable Drag Chain, bellows cover,Chip Conveyor,shredder for CNC machine ,Support arm System ,Machine Foot and etc. Our company had built a quality management and quality assurance system, and passed the certification of ISO 9001:2008 to make sure the product quality maintaining a high level. We have obtained high reputation from our customers for the high quality products, competitive price and best service. Innovation, honesty, and responsibility are our business philosophies that we are truthfully fulfilling. Devoting our efforts in product development, honestly responding to our customers, and responsibly engaging in sustainable operation and management. we always strive to improve our working processes, enhance our quality control and improve ability, we also set a high expectation for ourselves to create glories in the CNC machine tool accessories industry.
FAQ
1. who are we?
We are based in Shandong, China, start from 2004,sell to North America(30.00%),Domestic Market(25.00%),Oceania(10.00%),Eastern Asia(5.00%),Western Europe(5.00%),Southern Europe(5.00%),Northern Europe(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Southeast Asia(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Chip Conveyor, Support Arm System, Cable Drag Chain, Bellow Covers, Shredder

4. why should you buy from us not from other suppliers?
Export to EU, quality assurance! We are a 18-year manufacturing factory. There are 2 production lines We have 37 workers and 15 sales.Zhong de factory has passed ISO9001 quality system certification, our products have passed EU CE certification.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,FAS,CPT,DDP;
Accepted Payment Currency:USD,EUR,JPY,CAD,HKD,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi
