1325 CNC wood router.mp4
4 year agoThis kinds of CNC wood router is also called CNC Wood Carving Machine or CNC Wood Engraving Machine in the Wood CNC machine industry. It is a basic woodworking engraving cutting machine with strong welding steel tube frame and a T-slot vacuum table. Transon this 1325 1530 Wood CNC Machine is considered an entry-level machine in the woodworking machinery industry and favored by users at home and abroad. The wood router mainly performs some plane processing on the board. If you are just doing flat machining on some plates, this CNC wood router is definitely your ideal choice.
Of course, if you have other machining requirements such as three-dimensional work pieces, curved surface machining of complex work pieces, we also have CNC equipment such as 4-axis engraving machine, rotary axis engraving machine, ATC CNC router and multi-head engraving machine for you to choose.
Parameters:
TRANSON CNC Woodworking CNC Router
Model
TSW1325B/TSW1530B
Brand
TRANSON
X Y Worksize
1300x2500mm/ 1500x3000mm( can customize)
Z-axis Worksize
200mm
Control System
DSP(Mach3 USB, NC Studio, Syntec, etc Optional)
Spindle Power
3KW/ 4. 5KW/5.5KW/9KW Air Cooling(0-18000rpm)(Water Cooling and Higher Power Optional)
Table
T-slot aluminum/T-slot Vacuum(Optional)
Driver Motor
Stepper(China Easy Servo and Yaskawa Servo Optional)
Rail Guide
Square rails
Transmit
XY Gear Rack and Z Ballscrew
Working Speed
0-15000mm/min
Command Code
HPGL,G code
Working Precision
0.05mm
Working Voltage
AC220V士10%/50~60HZ,380V5060HZ,3 PHASE
Compatible Software
Tvpe3/Arcam/UG/Pro-e/Mastercam/Ucancam V10 etc
Dust Collector
With
Machine Size
305cm*200cm162cm/ 348cm*210cm*162cm
Package Size
316cm*213cm186cm/ 368cm*228cm*186cm
Net Weight
1150KGS/1380KGS
Gross Weight
1380KGS/1550KGS
Main application industries of the CNC wood router:
CNC Router for woodworking is not only limited in woodworking fields such as MDF cutting, wood panel cutting engraving, this cnc router machine can be used in many other industries such as advertising industry, craft industry, mold industry, electronics industry, construction industry, printing and packaging industry, decoration industry, tombstone industry, crystal products' industry, etc.
Applicate materials of CNC router:
CNC wood machine can meet the processing of most of non-metal materials like acrylic, PVC board, hibiscus board, two-color board, wood board, density board, marble, fire board, rubber board, glass, crystal.
Machine details:
1, 4.5KW air cooling spindle: cooled by fan, has the advantages of simple operation, convenient maintenance and low cost. No special maintenance is required, so maintenance and use costs are lower. This air cooling spindle is suitable for users with shortage of water resources. Of course, it is also an ideal choice for winter processing, especially for users in the north.
2, DSP handle controller,Handle control, no need to connect to a computer, it can save space. Simple operation, it is easier to learn and master. After power-off and restart, the machine has the function of automatic carving, which saves the tedious manual point matching and improves work efficiency. The failure rate is lower and the machine can run more smoothly.
3, 4 zone vacuum worktable with vacuum pump, for easy fix material.
4, YAKO brand stepper motor and driver, can run with smaller noise, lower heating, smoother movement and have better performances at higher speed. Can ensure the machine has a long service life. And to maximize the user's profit margins.
