KS925 Mini track loader

Main Demension

METRIC

U.S.

Machine weight (no attachment,fluids full)

1450kg

3196.7lb

Operating capacity

35% tipping capacity

454kg

1000lb

Tipping  capacity

1298kg

2861.6lb

A    Max. Operating height

2980mm

117in

B    Max. Hinge pin height

2210mm

86.5in

C    Overall height

1420mm

56in

D    Overall length (with standard bucket)

2980mm

117in

E    Overall length (without attachment)

2120mm

83.5in

F    Wheelbase

1180mm

46.5in

G    Unloading height

1750mm

69in

H    Max. safety distance

630mm

25in

I     Min. ground clearance

145mm

5.7in

J     Angle of departure

33°

K    Angle of approach

25°

L    Distance of support roller center to pedal

560mm

22in

M    Angle of unloading

25°

N    Max. horizontal pushing depth

90mm

3.5in

O    Overall width

932mm

36.7in

P    Chassis width

920mm

36.2in

Q    Track width

180mm

7in

POWER

METRIC

U.S.

Model No

Kubota D902

Fuel

Diesel

Gross power rating

15.82hp

11.8kw

Emissions compliance

EU Stage V

EPA Tier 4

Number of cylinders

3

Displacement

1.047L

63.89in³

Bore

72mm

2.83in

Stroke

73.6mm

2.9in

Rated speed

2300rpm

OPERATION

METRIC

U.S.

Ground drive speed

Forward/Reverse

5km/h

3.1mph

Ground pressure(ISO/CD 16754)

7-In(180-mm)tracks

0.33bar

4.78psi

HYDRAULIC SYSTEM I

Auxiliary circuit

Piston pump

Flow rate

89L/min

40.4gpm

Pressure

200bar

2900.75psi

FLUID CAPACITIES

Fuel tank capacity

42L

Lubricating oil capacity

4L

Hydraulic reservoir capacity

40L

BATTERY

SAE reserve capacity rating

110min

SAE cold crank@ 0° F (-18°C)

800amps

Electrical system

12V
