Cold Drawn Round Steel Bar

2 year ago

27 0 

7 year

Product details

1045 S45C C45 cold drawn steel round bar

1045 S45C C45 steel material is a medium carbon steel grade with good mechanical properties for a various applications. 1045 S45C C45 steel bar is usually used in many industries like automotive, agriculture, construction and motorcycle.

Specification of 1045 S45C C45 steel bar we supply:

Sizes	Wide range from 6mm to 100mm
Tolerances	Precision to h9, h10, h11
Roundness	75% of diameter tolerance
Straightness	Good straightness to 0.5mm/m
Surface roughness	Smooth to 1.6um
Mechanical properties	Yield strength and tensile strength can be improved
Machining	Suitable for machining and welding

1. 1045 S45C C45 steel equivalent material:

GB	ASTM/SAE/AISI	DIN	SCM	AS /NZS1444
45#	Aisi 1045 / sae 1045 / astm 1045	C45 CK45	S45C	AS 1045

2. 1045 S45C C45 steel chemical composition:

Material	Chemical Composition %
	C	Si	Mn	S	P	Cr	Mo
1045	0.42-0.48	0.15-0.35	0.60-0.90	0.035 max	0.035 max	0.035 max	0.035 max

3. 1045 S45C C45 normalized steel mechanical properties:

Mechanical Properties
Yield Strength (MPa)	Tensile Strength (MPa)	Elongation	Reduction of area	Hardness
400 min	640 min	222% min	54% min	32HRC max

4. 1045 S45C C45 steel applications:

Gears	Pins	Rams
Shafts	rollers	sockets
axles	spindles	worms
bolts	ratchets	Light gears
studs	crankshafts	Guide rods
Connecting rods	Torsion bars	Hydraulic clamps

4140 Cold Drawn Steel Bar Jpg

Except cold drawn steel Round Bar, we can also produce other shapes cold drawn steel bar such as Cold Drawn Round Bar, Cold Drawn Steel Square Bar, cold drawn flat bar and cold drawn Hexagonal Steel Bar. Except cold drawn steel bar, we can also do further processing for Turned Steel Bar, polished steel bar and centerless ground bar.
