SC SERIES STANDARD TIE ROD PNEUMATIC CYLINDER

Short Description:

SC series cylinder repairable, pneumatic heavy-duty cylinder conforming to NFPA, with tie rods, Pneumatic Cylinder Tube,NPT cylinder connections, piston rod threads in inches, and all other dimensions in inches too. Air Cylinder Barrel.The cost-optimized design makes this an ideal choice for OEM machinery manufacturers. Sturdy construction with stainless.

Characteristic

Double Ended Cylinders
1.SC series standard cylinder are producing conform to ISO 15552 ( ISO 6431, DIN ISO 6431, VDMA 24 562, NF E 49 003.1 and UNI 10290).
2.Very wide used in the automation field, especial in Europe market.
3.Normally bore size: 32mm, 40mm, 50mm, 63mm, 80mm, 100mm, 125mm,160mm,200...
4.With the same SC appearance, available built-in magnet, no protruding proximity sensors thanks to profile slots.
5.With self-lub bearing, the piston rod is lubrication free. And the adjustable air cushion keep the cylinder operating soomthly, safely and quietly.
6.Easier and various mounting via female threads or mounting accessories.
7.Supply cylinder kits, aluminium barrel, piston for customer assemble cylinder locally.Pneumatic Air Cylinder,

Feautres

Pneumatics is the technology that uses compressed air to operate different mechanisms. In the industrial sector it is used in multiple processes and applications.The pressure energy of compressed air is converted into mechanical energy, and the driving mechanism makes linear reciprocating motion, swinging and rotating motion.Aluminum Pneumatic Cylinder.
