Product details

Corrugated Line Overhead Bridge Part Corrugated Cardboard Conveyor Traction Belt

Overhead Bridge Part Corrugated Conveyor Traction Belt

Woven Bridge Crossing Belt(Traction Belt)

Knitting process: multi-layer single file
Material: polyester yarn, polyester filament
Features: clear braided lines, neat edges, stable size, heat and voltage resistance, antistatic, excellent traction,
The surface and seam are sealed evenly. Good absorption, dryness and antistatic property make the corrugated board transported perfectly and efficiently on the production line.
Service life: 80 million m service life under laboratory test conditions

Traction Belt for Paper Cardboard Machine

MODEL-FCH	EDGE REINFORCEMEN FCH-FZ	KEVLAR EDGE REINFORCEMEN FCH-JQ	TRACION BELT FCH-QY
NEIGHT KG/M2	7.5	7.5	3
THICKNESS mm	9.1±0.3	9.1±0.3	6±0.5
WIDTH mm	1400-3300	1400-3300	400-1400
THERMAL ENDURANCEºC	200ºC	200ºC	150ºC
FRICTION FACTOR	0.45	0.42	0.38
BREAKING STRENGTH KG/M	30000	32000	10500
MOISTURE ABSORPTION /RELEASE RATIO	129%	120%	----
STEAM LM2-H	6.560	6.051	----
FLEXIBILITY TRANSVERSE	0.96%/180ºC	0.93%/180ºC	----
FLEXIBILITY LONGITUDINAL	0.68%/180ºC	0.63%/180ºC	----

Suitable for BHS, MARQUIP, MITSUTBISHI, ISOWA, MINGWEI, FULI, AGNATI, etc

Industrial Belt for Paper Cardboard Machine

WHY CHOOSE US?

1,The first domestic machine capable of producing a conveyor belt with a large width of 3300 mm

2,Obtained a patent for the anti-collision edge

3The unique Company participating in the domestic industry standard customization of conveyor belts

4,The surface of the conveyor belt is made of Austrian imported Tencel, which improves water absorption and air permeability by 7.8%

5,Under normal circumstances ,it can be used for 80million meters or more

Corrugated Woven Belt for Corrugation Cardboard Machine

Corrugated Belt for Corrugation Cardboard Machine

Two Options For Joint, Flock Coating Or Hot Melt Glue

The joint made by the Hot Melt Glue curing process of high temperature resistant colloid can not only protect the steel buckle well, but also be firm and durable. It also ensures that the deviation between joint height and the belt surface is less than 0.2mm, which greatly reduces the cardboard production process Waste. It also solve the impact of indentation on cardboard printing

For E flute corrugated cardboard, flock coating joint is recommened.
Imported flocking glue is used, which is not easy to shed and is firm

Traction Belt for Corrugation Cardboard Machine

Apply polyester filament in the middle of the belt to make the belt not deformed . The longitudinal shrinkage rate of the belt is 0.9%

FEATURE

Anti-collision function: 200mm Aramid fiber material anti-collision edge, anti-collision and wear-resistant, patented design; provides stable cardboard transportation, reduces wear and static electricity, and ensures smooth production process.

Excellent water absorption function, 7.8% higher than the water absorption rate of ordinary conveyor belts;

Anti-static function, anti-static fibers are added to the upper and lower surfaces to make the conveyor belt have good conductivity, which can quickly release the static electricity in the conveyor belt.

It can eliminate static electricity generated between the conveyor belt and the cardboard, does not slip, adheres well to the cardboard, and increases the conveyor belt's ability to carry cardboard.

Transmission Belt for Corrugation Cardboard Machine

Q1: How long is the liftime of the conveyor belt?
A: Under normal circumstances (not operational error or mechanical failure), it can be used for 80million meters or more.

Q2: How about the fastest trial speed?
A: 330m/min.

Q3: Lead time?
A: Generally, 30-45 days. If the customer needs urgently, the lead time can be shortened.

Q4: Why is the price not the lowest among the industry?
A: The product process is different. Our factory has participated in the formulation of national standards, and the product hasobtained a patent for collision avoidance.

Q5: What corrugated cardboard production line has our conveyor belt used?
A: Suitable for BHS MARQUIP MITSUTBISHI ISOWA MINGWEI FULI AGNATI and ect
