High speed CNC circular band saw

Main feature:

1 This machine is a fully automatic high speed metal circular saw machine, it specially designed for cutting round

solid rods and square solid rods,according to customers requirements for high speed cutting and high precision

cutting. Saw cutting off speed:412mm/s. cut section roughness:3.2mu, saw section accuracy:0.05mm,

work accuracy: saw blade flange end/radial beat0.02mm,  saw section with workpiece axial line vertical

degree:0.02mm/100,  saw blade repeated positioning accuracy:≤±0.05mm,  The main parts of NST high-speed

metal circular saw machine are imported from Japan.2 the whole fuselage adopt QT500 spheroidal graphite cast iron.

guarantee rigidity of the fuselage structure.

Cutting range

Model/item

J-75

Bar

5~75mm

Angle materials

5~60mm

Round tube

5~75mm

Square tube

5~60mm

Cutting head structure

Use saw blade specification

dia285 *t1.75*t2.0mm

Saw blade rotation

70~200/Min

Main motor

7.5KW/4P

Tool gear gap compensation device

Magnetic powder brake

Saw blade deflection device

Tungsten carbide parallel block

Saw blade debris remove device

Active round wire brush

Cut feed way

Transverse and horizontal with roller guide way

Clamp way

By hydraulic/horizontal and vertical clamp each group

Self lubrication system

Variable injection timing of

Auto dispenser

Pneumatic reciprocating

Auto chip remove conveyor

Chain plate type remove

Oil mist cooling device

Oil mist lubrication sprayer

Cutting liquid cooling device

0.12kw circulating cooling

Working light

50w waterproof

Feeding device

Feeding clamp way

Hydraulic clamp

First cutting length

Min 10mm

Remaining tail materials length

Min 70mm

Feeding length

5~680mm

Automatic turnover material device

Allow materials length of feeder

Max 6000mm

Supply way

By hydraulic

Hydraulic device

Hydraulic motor

2.2KW/4P

Hydraulic driver pressure

70MPa

Capacity of hydraulic tank

120 liters

Working air pressure

4~6MPa

Machine size/weight

Size (L*W*H)

7000*2700*1800mm

Weight

2500kg

Main parts and suppliers

No

Parts name

Suppliers

1

Controller system

Mitsubishi

2

Main motor(7.5kw)

Siemens

3

Cutting servo motor(2kw)

Mitsubishi

4

Feeding servo motor(1.5kw)

Mitsubishi

5

Touch screen

Mitsubishi

6

Servo motor driver/actuator

Mitsubishi

7

Spindle frequency converter

Mitsubishi

8

Contactor

Schneider/Siemens

9

Roller guide rail

Taiwan HIWIN

10

Gear gap compensation device

Taiwan STEKI

11

Gear

Japan KHK

12

Bearing

Japan NTN/NSK

13

Hydraulic solenoid valve

Japan YUEKN

14

Ball screw

Taiwan HIWIN


2 (2)


Cutting Material

Process Equipment

Workshop

Certificate
