STEEL WIRE SPIRAL HYDRAULIC HOSE

8 month ago

4 0 

Luohe Letone Hydraulic Technology Co., Ltd

3 year

Product details

LT798

29000PSI ultra high pressure resin hose

Scope of application ：suitable for conveying media such as water and hydraulic oil under high pressure, widely used in high-pressure cleaning and other industries

Pressure range：2000bar (29000psi)

Inner rubber layer： Nylon

Reinforcement layer：four or six layers of high-strength super-flexible steel wire winding

Outer layer：black or colored polyurethane

Temperature range： -40℃ to +100℃ (-40℉ to +212℉)

Introducing our premium 29,000 PSI Ultra High Pressure Resin Hose - the ultimate solution for industries requiring exceptional strength and durability under intense pressure conditions. Crafted with cutting-edge technology, this hose is designed to withstand the most demanding applications, ensuring reliability and safety in various industrial settings.

Rated at 29,000 PSI: This hose is engineered to handle extremely high pressures, making it ideal for applications where standard hoses would fail.

Resistant to Chemicals and Abrasion: The inner lining of the hose is resistant to a wide range of chemicals and abrasions, ensuring longevity and reducing the risk of damage during use.

Compatibility: Suitable for use with various types of resins and fluids, providing versatility across different industrial processes.

Hose inner diameter I.D.			Outer diameter of hose O.D.	Working pressure W.P.		Burst pressure W.P.		Minimum bending radius MIN.B.P.	Reference weight W.T.
Dash	In.	mm	mm	MPa	psi	MPa	psi	mm	g/m
-3	3/16	4.8	14.5	200	29000	600	87000	220	600
-4	1/4	6.3	16.4	200	29000	600	87000	250	800
-6	3/8	9.5	21.2	200	29000	600	87000	300	1300
-8	1/2	12.7	25	200	29000	600	87000	320	1600

Note: The actual parameters are subject to the final atlas
