Small Ball Screw and Nuts

9 month ago

8 0 

Suzhou Industrial Park Hojama Technology Co., Ltd

2 year

Product details

Ball screw assemblies are low-friction transmission components designed to convert rotational motion into linear motion. They are also used to transform torque into axial reciprocating force and are commonly found in hydraulic and pneumatic power transmission systems. These assemblies consist of a threaded screw shaft and a nut with steel balls. As the screw or nut rotates, balls roll between the helical grooves of the screw and nut. The system incorporates a ball recirculation mechanism that allows the balls to travel continuously along a sealed circuit with minimal internal friction.

MIA1002: 10mm diameter ball screw

1. M: standard nut

2. I: internal deflector

3. A: round nut with triangular thread

4. Diameter: 10mm

5. Lead/Pitch: 2mm

6. Material: bearing steel or stainless steel

7. Accuracy Grade: C3/C5

Wide Application of miniature ball screws:

1. electronic machinery robot

2. measuring instruments

3. medical equipment

4. X-Y table

5. CNC Router\CNC grinding machine

Note:

1. Do not remove the ball screw nut from the miniature ball screw, as they are matched components and reinstallation may be difficult.

2. The product price is subject to the actual cost.

3. Sample provision is possible.
