The sports fence at the stadium has a unique regional division function and isolation protection effect. It separates the venue from the surrounding environment, preventing accidental injuries outside the venue caused by the flying of balls during the sports activities, protecting the people outside and road vehicles from being affected by the inside; at the same time, it can control the movement path of the ball, reducing the time and effort for athletes to retrieve and reset the ball; minimizing the interference factors outside to ensure the continuity and safety of the sports competitions inside the venue.
1. Column: φ76*3.0mm galvanized steel pipe + original polyester powder coating treatment
2. Upper and lower crossbars: φ60*2.0mm galvanized steel pipe + original polyester powder coating treatment
3. Mesh net: low-carbon galvanized iron wire + original high-density PE plastic coating process, wire diameter 2.3/3.8mm ± 0.15mm, mesh size 50*50mm ± 3mm
4. Net sheet fixation method: aluminum strip fixation (width 20*thickness 3.0mm)
5. Column spacing: 3000mm
6. Column installation method:
(1) Pre-buried fixed type, total height of the column: height of the net enclosure + 400mm, pre-buried 400mm
(2) Base plate fixed type, total height of the column: height of the net enclosure + flange plate
7. Fastening parts: precision steel stamping fasteners + 304 stainless steel screws, thickness 2.5mm
8. Color: dark green
| specification | price |
| 4*3 | 13.4 |
| 4*3 | 12.1 |
| 3*3 | 13.2 |
| 2*3 | 15.4 |
Product Features: The Yingliuo modular assembly safety net can be installed on-site without cutting or welding. It can be constructed and installed quickly, is safe and stable, and is easy to move. The structure, shape and size of the net can be adjusted at any time according to requirements.
Hot-dip Galvanizing Technology: The product's columns and crossbeams are made using hot-dip galvanizing technology. After thoroughly treating the rust layer on the steel surface and immersing it in a 600 high-temperature zinc solution, the zinc layer is tightly attached to the inner and outer walls of the steel, avoiding direct contact between the steel and the air, significantly enhancing the product's resistance to acid and alkali and weather resistance. This ensures the best anti-corrosion, rust prevention and aging resistance from the very beginning.
Spray coating process provides comprehensive anti-corrosion and rust resistance: After the surface of hot-dip galvanized steel is treated by shot blasting, under the action of high-voltage electrostatic force, pure polyester plastic powder is sprayed onto the surface of the steel, and the powder will be evenly adsorbed on the surface to form a powder-like coating; after the powder coating is baked at high temperature (180-200), it will level out and solidify, and the plastic powder particles will melt into a dense protective coating firmly adhering to the surface. This significantly enhances the product's resistance to acid and alkali and weather resistance, truly achieving all-weather, all-round, 360 comprehensive anti-corrosion and rust resistance.
Safe and stable, simple structure, easy installation: Using high-quality standard hot-dip galvanized steel pipes, with an "L" or "T" shape structure, no cutting and welding is required on-site, and installation is convenient.
Environmentally friendly and aesthetically pleasing: The frame surface is treated with spray coating and original PE coating. The color is bright, the smoothness is flat. The environmentally friendly materials are non-toxic and odorless, the color combinations are diverse, the appearance design is simple and dynamic; the surface is self-cleaning, no special care is required.
Personalized customization: According to the customer's needs, the product material can be selected, and the product specifications and accessories can be customized freely without any limitations.
Enlio company was established in 2007, and specialized in producing PVC Sports Flooring, Modular Court Tiles, Wet Area Mats, Kids Room Flooring, Dance Flooring, Multi- Purpose Flooring, and so on.
CNAS national accreditation laboratory, among the ranks of national accreditation laboratories.
The products is approved by BWF, ITTF, ITF, IHF, FIBA, FIBA 3X3. The products has passed CE, SGS, ROHS certification.
Enlio is the FIBA 3x3 Global Official Court Supplier 2019-2026, and is the FIBA 3x3 World Cup Official Court Supplier 2019-2026.
1. Are you manufacturer or trading company?
We are manufacturer with our own facilities and warehouse.
2. Can I customize my court size, color and logo?
Yes! We can do court design, color and logo customize as you wish.
3. Can you draw the court lines for me?
Yes! Auto lines marking service at factory is available for customers.
4. Can you provide warranty?
Yes! We provide 5 years' quality warranty and 10 years' backup support.
5. Can I get your samples?
Yes! You just pay for the express freight for small samples.
6. Are your products made of environmental materials?
All of our products are eco-friendly.
7. How long can I receive samples?
We usually is international express delivery, usually take about 3-4 working days.
8. How do I pay for my purchase order?
T/T, L/C, Trade Assurance, or others.
