Auto stacker

Automatic Stacker

A Complete Corrugating Board Production Line Includes The Following Machines: Mill Roll Stand, Pre-Heater, Splicer, Single Facer, Over Bridge, Multi-Pre-Heater, And Glue
Machine, Double Baker, Slitter Scorer, Cutoff, Stacker, And Ect.
Raw Paper Roll Is Fed To The Roll Stand, After Heated And Moisture Adjusted By The Per-Heater, Raw Paper Will Go To Tne Single Facer, Corrugated By It, And Gluing Together With Another Raw Paper To Become Single Faced Corrugating Paper, Then Conveyed Through The Over Bridge, Re-Heated By Multi-Pre-Heater, After Glued By Glue
Machine, Jointed By The Double Backer, Continuous Corrugating Board Comes Out.
After Slitting And Scoring By Slitter Scorer And Transverse Cutting By Cutoff, Corrugating Board With Different Sizes Are Produced. At Last, These Different Sizes Corrugating Board Will Be Stacked, Calculated And Than Send Out By The Stacker.
Heating Way: Steam Heating.

Paper Width(mm)	External Dimensions (mm) L*W*H	Weight(T)	Total Power of Motor(kW)
1400	18500*3800*3500	9	30
1600	18500*4000*3500	10	30
1800	18500*4200*3500	11	35
2000	18500*4400*3500	12	35
2200	18500*4600*3500	13	39
2300	18500*4700*3500	14	39



The conveyance device is divided into four sections to carry out accurate separation of cardboards by order/lot and make the cardboard stack more neatly.




SPECIFICATION

1. The feed-out rollers are driven by a frequency converter controlled frequency conversion motor, so the acceleration and
deceleration are stable, the cardboard output is smooth, and it is not easy to make the cardboard turnover.
2. The lifting platform is driven by a frequency converter controlled brake motor and gravity counterweights are installed, so the acceleration and deceleration are stable and forceful and the speed changeover is reasonable and effective; thus, the cardboard stacking is smoother, the folded marks on cardboard are avoided and the life of the machine is extended.
3. The feed-out rollers are arranged closely and are lifted together with the lifting platform to reduce waste paper sheets.
4. The sun gear for paper output is pneumatically controlled and the air circuit is specially designed, so the paper output is
stable and tidy.
5. The ascending arc of the conveyance platform is reasonable, so partial lifting, etc. of the cardboard will not occur during
conveyance.
