Product details

ADSS Fiber Optic Cable 48 Core

ADSS Fiber Optic Cable is an each- dielectric, tone- supporting( ADSS) adss fiber designed for easy and provident one- step installation in lot chines with tone- supporting installations where metallic couriers can not be used. The loose tube design provides stable performance over a wide temperature range and is compatible with any telecommunications- grade optic fiber. The string design can gauge distances over 600m While the concentric, tone- supporting string design allows easy, one- step installation The adss string is also available with a personal track- resistant polyethylene( TRPE) jacket suitable for installation in electric field capabilities up to 25 kV.

Item	ADSS Fiber Optic Cable
Fiber type	G652D
Span	50-1000m
Number of Loose tubes	4-288 Cores
Cable diameter	Depends on fiber counts
Attenuation Coefficient 1310nm	≤0.35dB/km
Attenuation Coefficient 1550nm	≤0.22dB/km
Rated tensile strength(RTS)	Depends on span
Allows the use of tension(MAT)	Depends on span
Strength member	Aramid yarn+FRP
Inner sheath	PE
Outer sheath	PE/AT Sheath

The adss fiber optic string features a central strengthen member made of frp, which providesnon-metallic support. fresh strength is handed by aramid. Drink to interrogate me about fiber optic string at any time.

The adss fiber string emulsion is made of jelly for inflexibility and continuity. The adss 24 loose material is generally MDPE but can be customized upon request.
