IoT Energy Management system
Internet of Things(IoT) technique can be widely used in industrial field such as energy management, wireless temperature sensors’ network and etc. In this case, Acrel IoT energy management system can provided both a cloud platform on website and a APP for mobile phone for our user’s to remotely monitor the energy and devices’ status in real-time while processing fault alarm in time just simply through their phones or PC without the need of heading to work-site places. Also, an one-click energy report generation function is possessed for a brief overview of recent energy consumption
Structure
System Value
Advantage
●Centralized monitoring: Remote devices upload data 24 hours a day.
● Self-registration: Users can register their own accounts and add devices through the mobile app.
● Energy Analysis: Get the energy consumption of the devices anytime, anywhere.
● Alarm: Once an alarm occurs on the device, the alarm data will be uploaded in real time and pushed by the app to relevant person.
IoT PC Platform
|
|
Parameters Monitoring ● Device status ● Device alarm ● Event List ● Energy Statistics |
Energy Report ● Daily average load ● Peak consumption ● Export energy report ● Load trend |
|
|
Alarm Report
● Alarm List ● Cause of Alarm ● Danger type ● Fault processing status |
Alarm Treat ● Submit alarm reason ● Upload site picture ● Detail description ● Push message through SMS/APP |
IoT Mobile App
|
|
|
|
Parameters Monitoring ● Real-time data ● History curve |
Energy Report ● Energy report of day,week,month,quarter,year ● One-click to export auto-generated energy report |
Alarm Report ● Alarm report list overview ● Cause of alarm |
Alarm Treat ● Relay the cause of alarm ● Upload site picture |
Rated Products
Product Name | Product Image | Function |
ADW210 IoT Wireless Multi-circuit Energy Meter |
|
● Measurement: 4 circuits 3 phase voltage,current,power,power factor ,etc. ● Max demand ● Communication:RS485 or LoRa |
ADW300 IoT Wireless Energy Meter |
|
● Measurement:3 Phase voltage,current,power,power factor,etc. ● Accuracy:1 ● Max demand ● Communication:RS485,LoRa,4G,NB or 2G |
ADL200 Single Phase Energy Meter |
|
●Accuracy: kWh: Class 0.5s ●Frequency: 45~65 Hz ●12 digits LCD display U, I, P, Q, PF, kWh ●Range of measuring: 000000.00~99999999 kWh ●Communication:RS485, Modbus-RTU |
ADL400 Three Phase Energy Meter |
|
●Accuracy: kWh: Class 0.5s ●Frequency: 45~65 Hz ●12 digits LCD display U, I, P, Q, PF, kWh ●Range of measuring: 000000.00~99999999 kWh ●Communication:RS485, Modbus-RTU |
AGF Multi-circuit DC Energy Monitoring Device |
|
●With 3-way switch status monitoring,collect the output empty contact status of DC 24(maximum) circuit breakers, lightning protection devices, etc. ●Range of voltage measuring: DC 0~1500V ●Communication:RS485,Modbus-RTU |
ATC600 Wireless Temperature Receiver |
|
●Temperature Data Transmission: 240 ●Communication:RS485 ●Type: C: Terminal mode; Z: Relay mode |
DJSF1352 DC Power Meter |
|
●Accuracy: kWh: Class 1S or 0.5s, with ±12V voltage output for hall sensor power supply ●Measurement: voltage, current, power, forward and reverse electric energy, wo-way metering ●Communication: RS485 |
AWT100 Gateway |
|
/ lorawan868/ lorawan923/ lora868 ● Downlink:RS485 ●Uplink:4G,WiFi or Ethernet/lorawan868/lorawan923/lora868 |
