Dongfeng Fuel Tank Truck.mp4
4 year agoWe are Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd., China, are specialized in exporting DONGFENG Commercail vehicles, Pasenger Vehicles, Special Purpose Vehicles and Construction machinery as following:
1. cargo trucks
2. Dump trucks (4x2, 6x4, 8x4)3. Special purpose truck
4. Truck head
5. Buses
Also, except this model, we can also provide Semi Trailer, Special Purpose Vehicles, Mining Dump Truck, Mini Passenger Vehicle, Passenger Vehicles etc..
Drive Mode | 8×4 | |
Chassis | DFL1311A3 | |
Engine | Model | Cummins ISLe290 30 |
Type | 6-cylinder in line, turbocharging, air cooling, inter cooling, electrical control common-rail engine | |
Max. power(Kw/rpm) | 213/2100 | |
Max. torque(N.m/rpm) | 105/1000-1900 | |
Bore /Stroke(mm) | 114×144.5 | |
Displacement(ml) | 8900 | |
Type of fuel | Diesel | |
Compression ratio | 16.6:1 | |
Gearbox | Model | 9JS119T-B |
Max.torque(N.m/rpm) | 1190 | |
Dimensions | Overall dimension (mm) | 11980×2500×3200 |
Wheel base (mm) | 1950+4250+1300 | |
Front/Rear tread(mm) | 1940/1860 | |
App./Dep. Angle(°) | 20/13 | |
Mass | Payload (kg) | 17965 |
Curb weight(kg) | 12505 | |
G.V.W (kg) | 30600 | |
Overall dimension of tank (Length*Macro axis*Minor axis) (mm) | 9200×2250×1450 | |
Effective Volume(m³) | 28 | |
Tansport Medium | all kinds of oils, chemical liquids | |
Material of tank | carbon steel/stainless | |
It has the functions of oil absorption, oil pumping and etc. The tax control computor tanker, 15m oil reel, self-zeroing flow meter and oil gun are optional. |
