Tube Pipe Parting Machine

Computer PLC numerical control pipe cutting machine

Computer PLC numerical control pipe cutting machine has double servo precision automatia pipe cutting machine, suitable for all kinds of pipe material, and the soild pipe cutting, especially suitable for the mass production of the enterprise,the most advanced double servo positioning system,hydraulic clamping feeding. Make up the previous machine of rust, bending the disadvantages of insufficient material, eliminate waste.High Processing Tube Pipe Parting Machine have High reliability, good precision maintenance and convenient maintenance.

Model: SFPM80 type for (OD 45mm to 80 mm)

· Machining diameter: Ø 45- Ø80

· Motor Power: 3KW  6G

· Protection: The spindle motor automatically stops when no action

· Power supple: three-phase four-wire 380V 50HZ

· Feed speed: 0-10cm/s

· Productivity is:6000-8000pcs/8 hours

· Dimension (L*W*H)mm: 2000*1000*1700

· Machine weight approx: 900KG
