Surge arresters and insulators introduction
7 month ago
Electrical distribution type 10kA lightning arrester
| Type | Rated voltage(kV) | Continuous operating voltage(kV) | Residual voltage(kV) | 2ms rectangular current impulse withstand(A) | High current impulse of 4/10μS(kA) | Line discharge class | ||||
| 8/20μS lightning current impulse | 1/10μS steep current | 30/60μS switching current impulse | ||||||||
| YH10W-3 | 3 | 2.55 | 9 | 9.5 | 7.7 | 250 | 100 | 1 | ||
| YH10W-6 | 6 | 5.1 | 18 | 19 | 15.4 | 250 | 100 | 1 | ||
| YH10W-9 | 9 | 7.65 | 27 | 28.5 | 23.1 | 250 | 100 | 1 | ||
| YH10W-12 | 12 | 10.2 | 36 | 38 | 30.8 | 250 | 100 | 1 | ||
| YH10W-15 | 15 | 12.7 | 45 | 47.5 | 38.5 | 250 | 100 | 1 | ||
| YH10W-18 | 18 | 15.3 | 54 | 57 | 46.2 | 250 | 100 | 1 | ||
| YH10W-21 | 21 | 17 | 63 | 66.5 | 53.9 | 250 | 100 | 1 | ||
| YH10W-21 | 24 | 19.2 | 72 | 76 | 61.6 | 250 | 100 | 1 | ||
| YH10W-27 | 27 | 21.9 | 81 | 85.8 | 69.3 | 250 | 100 | 1 | ||
| YH10W-30 | 30 | 24.4 | 90 | 95 | 76.5 | 250 | 100 | 1 | ||
| YH10W-33 | 33 | 26.8 | 99 | 104.5 | 84.7 | 250 | 100 | 1 | ||
| YH10W-36 | 36 | 29 | 108 | 114 | 92.4 | 250 | 100 | 1 | ||
Characteristics
1).Silicone rubber & Zinc oxide.
2).Excellent antifouling performance.
3).Good acid and alkalis resistance.
4).Each Surge Arrester is tested before shipment.
5).IEC standard.
6).ISO9001 and ISO14001 manufacturer.
