PC Sheet 0.5mm
4 year ago
Product details
Product Composition
The main component of PC Sheet is based on polycarbonate (PC) resin.
Performance Characteristics
1. Impact resistance: The strength is 250-300 times that of ordinary glass.
2. Lightweight: The density is 1/2 of glass, reducing transportation and installation costs.
3. Temperature resistance: The operating temperature range is -40℃ to 120℃, and it can withstand 130℃ in a short term.
4. Light transmittance: up to 85%-89%.
5. Anti-ultraviolet: UV coating prevents yellowing and protects the life of the material.
6. Weather resistance: Anti-ultraviolet, ozone and extreme climate, high outdoor stability.
7. Flame retardant: Meets B1 standard, self-extinguishing and non-toxic.
8. Sound insulation and heat insulation: The sound insulation is 3-4dB higher than glass, and the hollow structure saves energy by 7%-25%.
Advantages
PC board is a thermoplastic engineering plastic with good transparency, outstanding impact resistance, creep resistance, high tensile strength, bending strength, elongation at break and rigidity, high heat resistance and cold resistance, and excellent comprehensive performance. Polycarbonate (PC) is widely used in the automotive, construction, medical and other industries due to its good performance.
Application Fields
1. Architecture and lighting: industrial workshops, greenhouses, lighting corridors, etc.
2. Automobiles and transportation: car windows, dashboards, central control screens, etc.
3. Safety protection: bulletproof glass, explosion-proof shields, military protection, etc.
4. Electronics and industry: electronic equipment housings, anti-static materials, industrial protective covers, etc.
5. Advertising and decoration: advertising light boxes, exhibition layouts, indoor and outdoor decoration, etc.
Our company is deeply engaged in the field of high-performance engineering plastics and insulation materials, and is committed to providing innovative material solutions for the global high-end manufacturing industry. Our main products include high-end engineering plastic sheets/rods such as polyoxymethylene (POM), ABS, nylon (PA), polycarbonate (PC), polyphenylene sulfide (PPS), polyetherimide (PEI), polyetheretherketone (PEEK), etc. We also provide special insulation materials such as bakelite (phenolic laminate) and epoxy glass fiber board. With excellent properties such as high temperature resistance, wear resistance, and high strength, our products are widely used in new energy vehicles, smart electronics, industrial machinery, aerospace and other fields.
FAQ
1. Q: How strong is the impact resistance of bulletproof PC board? What is the difference with bulletproof glass?
A: The impact resistance of our PC board is 250-300 times that of ordinary glass, and 6mm thickness can reach the bulletproof level. Traditional bulletproof glass relies on a multi-layer laminated structure, weighs more than 4 times that of PC board, and is easy to break as a whole after impact; PC board absorbs energy through molecular chain extension, only partially dents, and has no risk of splashing.
2. Q: How to avoid yellowing and brittleness of PC board during long-term outdoor use?
A: Using double-sided co-extrusion UV coating process, the nano-level protective layer (50-80nm) filters 99% of ultraviolet rays and passes the highest level certification of UL746C-F1. After 5 years of accelerated aging under strong sunlight in Florida, the transmittance only decreased by 3%-6%, while the attenuation rate of ordinary PC board reached 27%. Ordinary acrylic board has no UV layer and turns yellow obviously in 2 years.
3. Q: Can PC boards withstand extreme climates? Will they crack at low temperatures?
A: The operating temperature ranges from -40℃ to 120℃, and can withstand 130℃ in the short term. It was measured that there was no cracking at -30℃ ice cone impact, and no softening and deformation at 120℃. Acrylic boards become brittle at -10℃ and soften at 70℃. UL certification ensures that the physical properties of the material are stable under temperature differences and humid and hot environments.
4. Q: How does the lightweight feature reduce the overall cost?
A: The density is only 1.2g/cm³ (half of glass), which reduces transportation energy consumption by 40% and increases installation efficiency by 50%. For example, 10mm thick glass requires heavy brackets, while PC boards with the same protection can simplify the structure and reduce the overall cost by 30%.
5. Q: Is the sound insulation and heat insulation performance better than glass?
A: Hollow structure design, sound insulation is 3-4dB higher than glass (such as 6mm board sound insulation of 30dB), and heat insulation is improved by 7%-25%. The factory measured the hollow PC roof, the indoor temperature dropped by 5-8℃ in summer, and the air conditioning energy consumption was saved by 20%.
6. Q: Is the flame retardant performance reliable? Is the combustion toxic?
A: Passed GB50222 B1 flame retardant certification, ignition point 580℃, self-extinguishing and burning without toxic smoke. Ordinary PVC releases hydrogen chloride when burned, and acrylic board is flammable and produces molten droplets.
