Installation of Large size 5 axis waterjet 3D cutting machine in Customer's facility
2 year ago5 Axis CNC Water Jet Machine
---MAX 5 SERIES
We have produced many models of this Max series 5 axis waterjet cutting machine, including G series and L series cutting platform.
G series is large machines, for example, the waterjet 3D cutting range is 3500mm×7000mm or 3000mm×8000mm, as can be seen in the following picture.
L series are standard size gantry structure cutting platform, such as 3000mm×2000mm and so on.
5 Axis cutting is already a very mature technology, please feel free to buy.
3D waterjet cutting head Technical Parameters
Bevel axis (A): ±45°
Rotary axis (C): ±540°
Control accuracy: ±0.01mm
Angle accuracy: 0.01°
|
|
DETAILS
PARAMETERS OF CUTTING TABLE
3D WATERJET CUTTING SAMPLES
HIGH PRESSURE PUMP
Customers can choose YC pump or HYPERTHERM pumps, We have been cooperated with USA Hypertherm/Accustream since the year 2008.
CNC CONTROLLING SYSTEM
For thie Max 5 waterjet machine, customer can choose IGEMS nesting and programming software. IGEMS is a modern CAD / CAM / NEST software designed for waterjet cutting machines. With our massive knowledge within waterjet cutting, and the limitless usage of
the machine, we’re trying to build products that serve our customers, not the other way around.
