14 tph 14ton Coal Biomass Fired Steam Boiler
The 4-6t/h biomass fired steam boiler is of quick fitting tube structure, exit shop after completely assembled, the industrial biomass steam boiler of 6-35t/h is composed of 2 main components. The upper assembled component is the biomass fired steam boiler proper heat absorbing part, and the lower assembled component is of combustion equipment. The former part of the biomass fired steam boiler proper is arranged a membrane wall, the upper part of it is connected to biomass fired steam boiler cylinder, and its lower part is connected to collective chest, so as to form a combustion room and absorb the radiated heat from the furnace.
1.Model:SZL(A)
2.Capacity:2 ton/h to 40 ton/h
3.Design pressure:1.0Mpa(10bar/10kg/145psi), 1.25Mpa(13bar/13kg/180psi), 1.6Mpa(16bar/16kg/232psi),2.5Mpa(25bar/25kg/362psi), other pressure need to be specially design.
4.Stem temperature:184℃,194℃,205℃,226℃,other temperature need to be specially design.
5.Design fuel:coal,biomass,palm oil shell,wood chips,biomass pellet,cashew nut, rice husk,solid fuel,etc
6.Structure: double drum water tube "A" type
| Boiler model | Rated capacity |
Rated pressure
|
Rated steam temp.
|
Feed water temp. | Exhaust gas temp. | Design effiency | Boiler water volume | Weight | Dimension | Delivery mode |
| ton/h | Mpa | ℃ | m2 | ℃ | % | m3 | ton | mm | ||
| SZL2 | 2 |
1.25/1.6/ 2.5/3.82 |
194/204/ 226/450 |
20/105 | 130.67 | 83.13 | 6.76 | 22 | 5900×2850×3460 | Package |
| SZL4 | 4 | 142 | 84.23 | 5.1 | 29 | 6460×3280×3462 | Package | |||
| SZL6 | 6 | 142 | 84.81 | 8.4 | 34 | 7830×3560×3462 | Package | |||
| SZL8 | 8 | 149.15 | 85.02 | 9.4 | 40.5 | 8870×3670×3462 | Package | |||
| SZL10 | 10 | 152.7 | 86.2 | 8.35 | 24 | 7645×3180×3526 | Assembly | |||
| SZL12 | 12 | 148.7 | 86.56 | 12.8 | 37 | 9258×3294×3524 | Assembly | |||
| SZL15 | 15 | 149.86 | 86.29 | 15.5 | 24.7 | 11010×3300×2200 | Assembly | |||
| SZL20 | 20 | 147.4 | 86.8 | 15.8 | 25.97 | 16680×6200×8420 | Assembly | |||
| SZL25 | 25 | 149.6 | 86.4 | 16.5 | 28 | 8300×3000×3600 | Semi-Assembly | |||
| SZL30 | 30 | 148.6 | 86.8 | 16.8 | 29 | 8500×3600×3640 | Semi-Assembly | |||
|
Notice: 1.special proposal is available according to different place's different encironmental requirements; 2. burning fuel's heat value/chemincal component different, parameter different; 3.Since the boiler technology is keep updating, if there is any update in the future, no special imform. |
||||||||||
Pre-sale service:
We help customer choose the best boiler model according to different requirements of various industry. Before delivery we will provide foundation drawing, layout drawing, boiler room layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the production process to ensure on time delivery with perfect finished product.
After-sale service:
1.provide full range of original spare parts.
2.Engineers abroad installation and commissioning service is available.
3.Our engineers will held a training for boiler workers to ensure the safe operation.
4.Free maintenance and repair for one year and lifelong service.
