Product details

With Push-in connection technology, you can connect conductors from 0.25 mm² easily – both directly and without tools. The special contact spring enables easy insertion and guarantees a high level of contact quality.

Time-saving connection of pre-treated and rigid conductors with tool-free direct connection technology
Convenient insertion with 50% lower insertion force
Safe wiring and operation with color-coded push button
Connection of all conductor types with convenient front connection
The conductor can be easily released without special tools
Reduction in logistics costs with the uniform CLIPLINE complete system accessories

Technical Parameters

Model Number	JPT 1.5/S
Color	Grey, Blue, other color can be customized
Length/Height/Wide (mm)	45/32/3.5
Connection method	Push-in connection
Material	Nylon PA66
Rated Voltage/Current	500V/17.5A
Cross section, solid/soft Cable	0.14-1.5 mm² / 0.14-1.5 mm²
Conductor Size	26-16 AWG
Mounting Type	NS 35/7.5
Standard	IEC 60947-7-1
LOGO	Customized logo are supported
Packing Detail	3.29g/pc, 100PCS/BOX
Certification	CE/RoHS/CQC/ISO 9001

1_01

Technical Parameters

Model Number	JPT 1.5/S
Color	Grey, Blue, other color can be customized
Length/Height/Wide (mm)	45/32/3.5
Connection method	Push-in connection
Material	Nylon PA66
Rated Voltage/Current	500V/17.5A
Cross section, solid/soft Cable	0.14-1.5 mm² / 0.14-1.5 mm²
Conductor Size	26-16 AWG
Mounting Type	NS 35/7.5
Standard	IEC 60947-7-1
LOGO	Customized logo are supported
Packing Detail	3.29g/pc, 100PCS/BOX
Certification	CE/RoHS/CQC/ISO 9001

PT4_11 PT4_111 PT4_1111
