PSHJ-20 lab twin screw extruder
5 year ago
PSHJ Co-rotating Twin Screw Extruder
The XINDA PSHJ twin screw series are built on a modular system. The major advantage of this modular design is the versatile configurations. Processing tasks can be optimally accomplished with only a few barrel and screw variations.
Application:
Color masterbatch/Concentrates
Key words:
Pvc Compounding Line
Compounding Extruder
Forming Masterbatch Extruder
Compounding System Line
Co-kneader For Toner
| Model | PSHJ-20 | PSHJ-35 | PSHJ-50 | PSHJ-65 | PSHJ-75 | PSHJ-127 |
|
Screw Diameter: MM |
φ21.7 |
φ35.6 |
φ50.5 |
φ62.4 |
φ71 |
φ126 |
|
Central Diameter |
18 | 30 | 42 | 52 | 60 | 102 |
|
Length Diameter Ratio L/D |
28-52 | 28-52 | 28-52 | 28-52 | 28-52 | 13-18 |
|
Main motor power KW |
4~5.5 | 22~45 | 75~110 | 110~185 | 160~280 | 90~160 |
| Max screw speed | 600 |
600 |
600 |
600 |
600 |
600 |
|
Outout torque per Shaft N.m |
32~43 | 175~358 | 597~875 | 875~1472 | 1273~2228 | 850~1528 |
|
Reference Output KG/Hour |
5~20 | 20~80 | 80~200 | 150~350 | 300~600 | 800~1500 |
