Product details

XN12 Mini Excavator with kubota engine or Yanmar engine, swing boom, telescopic tracks.

Product Description

Specification

1. The four-post ceiling is stronger. 2. New style seat,more comfortable. 3. Optional swing boom,more flexible for narrow space operation 4. Oil cooler can be used,which can work in high temperature areas for a long time 5. Well-known single-cylinder air-cooled engine 6. Wide range of application,saving time and fuel.

Brand	RHINOCEROS/RHINO/XINIU
Operating Weight	1040kg
Digging bucket capacity	0.025cbm/120kg
Digging bucket width	350mm, can add narrow bucket is 200mm
Engine	Kubota
Rated power	10.2KW
Displacement	6.8ml/r
Bore stroke	Three cylinders, water cool
Main pump	SAISIDA
Valve	BEIFANG
Swing motor	SJ-TECH (MP-1-160)
Traveling motor	KERSEN (OMS-2450)
MAIN DEMENSIONS
Overall dimension( LxWxH)	2770x896x1490 mm
Wheelbase	910 mm
Total length of track on land	1230mm
Platform ground clearance	380 mm
Platform back turning radius	784 mm
Chassis width	896 mm
Track width	180 mm
Chassis ground clearance	132 mm
Track height	320 mm
OPERATING RANGE
Max. Digging depth	1650 mm
Max. Vertical digging depth	1375 mm
Max. Digging height	2610 mm
Max. Dumping height	1850 mm
Max. Digging radius on ground	2850 mm
Min. Rotation radius	1330 mm
Max. Upgrade height of bulldozer blade	345 mm
Max. Digging depth of bulldozer blade	255 mm
