Welded Wire Mesh Fence Panel – Rigid Perimeter Enclosure for Security & Boundary Protection
Wire Ø3.0–6.0mm | Mesh 50×50 to 200×50mm | Panel Height 0.6–2.4m | HDG / PVC / Powder Coated | Welded Construction
ISO 9001:2015 30+ Years Manufacturing 72,000m² Factory SGS Audited
HEBEI CONQUER HARDWARE WIRE MESH CO.,LTD (ANJIA Group) manufactures welded wire mesh fence panels — also known as welded mesh fencing or rigid mesh panels — from a 72,000m² ISO 9001:2015 certified facility. Each panel consists of low‑carbon steel wires resistance‑welded at every intersection to form a rigid, dimensionally stable grid. The welded joints eliminate the risk of wire slippage under load, providing consistent mesh opening across the entire panel. Whether you need 1.2m green PVC‑coated panels for a residential boundary, 1.8m hot‑dip galvanized panels for a warehouse compound, or 2.4m heavy‑gauge panels for an industrial site — we produce to the exact wire diameter, mesh aperture, panel dimension and coating your project specifies. Wire diameter: Ø3.0mm to Ø6.0mm. Mesh opening: 50×50mm, 50×100mm, 50×150mm, 100×100mm, 200×50mm. Panel height: 0.6m to 2.4m. Panel width: 2.0m or 2.5m standard. Two welding process routes are available: weld first, then hot‑dip galvanize (best corrosion protection at joints); or pre‑galvanized wire welded, then PVC/powder coated (cost‑effective for less corrosive environments). Finishes: hot‑dipped galvanized (≥55μm), HDG + PVC coated (RAL 6005 green, RAL 7016 grey), or HDG + polyester powder coated. Posts: square tube 40×40 to 60×60mm or round Ø48mm. Complete with clamps, fasteners and post caps. Free samples, 20–40 day container loading, full ODM/OEM.
Related products: chain link fence | temporary fence panels | 358 anti‑climb security fence | welded wire mesh
Welding Process & Coating Options
Weld First, Then HDG: Panels are fully welded, then immersed in molten zinc. Every joint receives complete zinc coverage. Recommended for outdoor perimeters and corrosive environments.
Pre‑Galvanized Wire + PVC/Powder: Galvanized wire is welded into panels, then PVC or powder coated. Cost‑effective for residential and light commercial use.
Surface Finishes: HDG (≥55μm to EN ISO 1461), HDG + PVC (RAL 6005 green, RAL 7016 grey), HDG + Polyester Powder (custom RAL available).
Typical Applications
Residential Boundary Fencing · Commercial Property Enclosures · Warehouse & Factory Compounds · Grassland & Farm Boundaries · Public Parks & Schools · Utility Substation Fencing · Car Park Perimeters · Garden Enclosures
ANJIA Group – Welded Mesh Fence Manufacturer Since 1996
Hebei Conquer Hardware Wire Mesh Co., Ltd. is a subsidiary of Anjia Group, with over 30 years of production experience. Our 72,000m² facility in Anping, China, integrates wire drawing, automatic resistance welding, hot‑dip galvanizing, PVC/powder coating and packing lines. We hold ISO 9001:2015, ISO 14001, and all products pass SGS inspection. Welded wire mesh fence panels are exported to over 80 countries for perimeter security, boundary demarcation and enclosure applications.
