Product details
Ertalon® MC901 Sheet for Industrial Use
Among the various types of nylon sheets available in the market, MC901 sheet stands out as a popular choice for industrial applications due to its superior mechanical properties and versatility. Also referred to as Casting Nylon sheet or Casting MC Nylon sheet, this material is produced through a casting process that enhances its structural integrity and performance characteristics. It exhibits low friction, which makes it suitable for moving parts and sliding applications.
The casting process used in the production of Casting Nylon sheet allows for greater control over the material's structure, resulting in improved impact resistance and reduced internal stresses. As a result, products made from MC Nylon Sheet are less likely to crack or break under pressure, ensuring a longer service life. In addition to its mechanical properties, MC Nylon Sheet is also valued for its ease of processing. It can be easily cut, drilled, and machined using standard tools, making it a practical option for both small-scale and large-scale manufacturing. Its thermal stability allows it to maintain its shape and performance even at elevated temperatures, which is crucial for applications in high-heat environments.
casting mc nylon sheet 10mm
Characteristics
Ertalon™ Casting MC Nylon sheet
Mechanical performance
High strength and rigidity: The tensile strength can reach 80-120 MPa, and the bending strength is ≥ 150 MPa, which is better than ordinary nylon sheets.
High hardness: Rockwell hardness (HRR) ≥ 110, excellent impact resistance (notch impact strength ≥ 6 kJ/m ²).
Dimensional stability: Low coefficient of thermal expansion (CTE ≈ 6-8 × 10 ⁻⁵/℃), not easily deformed after long-term use.
Physical performance
Wear resistance: High surface hardness, low friction coefficient (μ ≈ 0.1-0.3), wear resistance life is 3-5 times that of metal materials.
Self lubrication: It can work under dry friction conditions without the need for additional lubricants, reducing maintenance costs.
Chemical resistance: Resistant to weak acids, weak bases, and organic solvents (such as gasoline and lubricants), but not to strong acids (such as concentrated sulfuric acid) and halogenated hydrocarbons.
Processing performance
It can be processed through mechanical means such as cutting, drilling, and tapping, as well as hot forming (hot bending, welding), to meet the requirements of complex working conditions.
The surface is smooth and flat, making it easy for secondary processing such as painting and film coating.
Environmental adaptability
Wide temperature resistance range: Long term use temperature of -40 ℃~120 ℃, short-term temperature resistance can reach 150 ℃.
Low water absorption rate (≤ 1.5%) and better dimensional stability than ordinary nylon.
Advantages
Balanced performance: It combines high strength, wear resistance, self-lubricating properties, and chemical corrosion resistance, with comprehensive performance superior to ordinary nylon sheets.
Lightweight: With a density of approximately 1.15 g/cm ³, it is 50% -70% lighter than metals such as steel and aluminum, reducing equipment load.
Long lifespan: significantly improved wear resistance, reduced replacement frequency, and lowered maintenance costs.
Environmental friendliness: recyclable, meets environmental requirements, suitable for food grade or clean environments (must comply with FDA/USDA standards).
Economy: Lower than metal processing costs and no need for additional lubrication systems, saving operating expenses.
