Product details

Polyamide PA6 Sheet with Excellent Shock Absorption pa6 vs pa12

Product Advantages

Balance of high strength and high rigidity: The mechanical properties of glass fiber reinforcement are close to those of metals, and it can replace aluminum alloy or zinc alloy for structural parts, significantly reducing the weight of components.

Outstanding wear resistance and self-lubrication: Suitable for high friction and high wear environments (such as gears and bearings), reducing lubrication requirements and maintenance costs.

High temperature resistance and fatigue resistance: It can still maintain high strength in environments above 100°C, and its performance decays slowly under long-term cyclic loads, which is suitable for dynamic application scenarios.

Processing economy: It can efficiently form complex shapes through injection molding and extrusion, with high material utilization; waste materials can be recycled and reused (recycling rate>80%), which is in line with the concept of sustainable manufacturing.

The core value of Nylon PA6 Sheet lies in its comprehensive characteristics of "high strength-wear resistance-high temperature resistance". It is suitable for fields that need to withstand mechanical loads, friction and wear or high temperature environments, especially in the automotive, machinery manufacturing, electronics and consumer products industries. Its typical application scenarios include:

Automobile and rail transportation: engine peripheral parts, gears, bearings, etc.
Mechanical manufacturing: wear-resistant linings, guide rails, fasteners, etc.
Electronic and electrical: insulating structural parts, connector housings, etc.
Consumer products: sports equipment, home appliance parts, etc.

pa6 nylon sheet

Data Sheet

Properties	Standard	Unit	Test Data
Specific gravity	ISO 1183	g/cm3	1.14
Water absorption	ISO 62	%	3.0
Flammability	UL94		HB
Mechancial Properties
Yield stress	ISO 527	Mpa	71.2
Elongation at break	ISO 527	%	50
Tensile modulus of elasticity	ISO 527	Mpa	2610
Notched impact strength	ISO 179	kJ/m2	7.6
Notched izod impact strength	ISO 180	kJ/m2	7.67
Shore hardness	ISO 868	scale D	85

The core reason for choosing Nylon PA6 Sheet is its comprehensive advantages of "high performance-lightweight-economy", which can accurately match the multi-dimensional requirements of modern industry for materials of "high strength, wear resistance, high temperature resistance, and easy processing", especially in the scenario of replacing traditional metal materials or general plastics.

pa6 sheets

Technical performance

High strength and high rigidity, an ideal choice for replacing metal

The tensile strength (100-150MPa) and flexural modulus (5000-8000MPa) of glass fiber reinforced PA6 sheet are close to those of aluminum alloy (such as the tensile strength of 6061-T6 aluminum alloy is about 310MPa and the flexural modulus is about 70GPa), but the density is only 1/4-1/7 of that of metal. In scenarios such as automobile engine brackets and rail transit equipment connectors, it can directly reduce weight by 30%-50% and significantly reduce energy consumption (such as lightweighting of automobiles can reduce fuel consumption by 5%-8%).

High fatigue resistance (slow performance decay under cyclic load) makes it suitable for structural parts (such as gears and bearings) that are subjected to long-term vibration or impact, avoiding sudden failure of metal parts due to fatigue cracks.

Self-lubricating and wear-resistant, reducing maintenance costs

The friction coefficient is low (0.15-0.3), and the wear rate is less than 0.1cm³/10⁴cm², which is much better than POM (polyoxymethylene) and PP (polypropylene). In high-friction scenarios such as conveyor belt guides and machine tool sliders, long-term stable operation can be achieved without additional lubrication, reducing the frequency of downtime maintenance (such as the life of mining machinery linings increased by 3-5 times).

Excellent tolerance to media such as lubricating oil and hydraulic oil, suitable for industrial equipment with complex lubrication environments (such as gearbox synchronizer rings).

High temperature resistance and chemical resistance, broadening the application boundaries

The heat deformation temperature (150-180℃) and long-term use temperature (-40℃ to 120℃) of glass fiber reinforced PA6 far exceed HDPE (up to 100℃) and ABS (up to 90℃), and can work stably in high-temperature engine compartments, steam sterilization equipment and other scenarios.

Its tolerance to media such as weak acids, weak alkalis and lubricating oils is better than that of ABS and PP, and it is suitable for corrosive environments such as chemical storage tank linings and food processing machinery parts.

Why not other materials?

Compared with metals (such as aluminum alloys and steel): PA6 sheets have significant weight reduction effects, lower processing costs, and do not require anti-corrosion treatment; although the strength is slightly lower than that of metals, it can meet the needs of most structural parts through enhanced modification.
Compared with general plastics (such as PP and HDPE): PA6 has comprehensive rigidity, wear resistance and temperature resistance, and is especially suitable for high-load or high-temperature environments.
Compared with engineering plastics (such as POM and PA66): PA6 has a lower price, better processing fluidity, and is suitable for complex structural parts; although the water absorption rate is high, the size can be stabilized through humidity control treatment, and the overall cost performance is better.
