Automotive OBDII Cable with Diagnostic Harness

12 month ago

46 0 

2 year

Product details

The Heavy-Duty OBD Harness Diagnostic Cable is designed for professional automotive diagnostic applications that demand strength, durability, and precision. Manufactured with premium-grade materials, it delivers stable conductivity and long-lasting reliability even under continuous use. Its reinforced harness structure ensures strong resistance to bending, pulling, and external interference, making it an ideal choice for workshops, garages, and automotive testing environments where performance consistency is critical.

Automotive Diagnostic Connector Cables and Wires

This diagnostic cable is compatible with a wide range of automotive diagnostic cables and integrates seamlessly with professional testing tools. It supports multiple connection standards, including car diagnostic cable, vehicle diagnostic cable, and universal OBDII cable systems, ensuring broad adaptability across different brands and vehicle types. The cable design minimizes signal loss and interference, providing fast, accurate, and real-time data transfer essential for effective troubleshooting and system analysis.

Item	Description
Product Name	Heavy-Duty OBD Harness Diagnostic Cable
Type	Heavy-Duty Multi-Branch OBD Signal Breakout Diagnostic Wiring Harness
Voltage	12V/24V DC, Customized Available
Pins Material	Nickel-Plated Brass Terminals & Pins, Gold-Plating Optional
Plug Material	PA66+GF Automotive Grade OBDII 16Pin Male Connector Housing, Multi-Color Thick PVC Insulated Single-Core Signal Wires, Assorted Green Mini Plastic Connectors & Metal Pin Terminals, Reinforced Strain Relief at Main Cable Branch Point
Working Temperature	-40℃~+105℃ Or Customized
Length	350±30mm / Customized Length Available
Minimum Insulation Resistance	≥10MΩ
Maximum Conduction Resistance	≤2Ω
Application Fields	Heavy-duty truck & commercial vehicle OBD signal testing, diesel engine ECU pinout diagnosis, auto repair shop multi-point circuit detection, construction machinery & agricultural vehicle diagnostic wiring, automotive electronic R&D bench testing, fleet monitoring equipment signal expansion, custom heavy-duty OBD breakout harness for diagnostic tool development
Specific Shipping Cost	Please Contact Us

The Heavy-Duty OBD Harness Diagnostic Cable also works efficiently within automotive cable assembly and vehicle cable assembly systems, making it a versatile solution for modern automotive wiring and electronic diagnostic requirements. In addition, it is compatible with connector cables and automotive cable and connectors, extending its application in both OEM production and after-market repair services. By combining rugged durability with high signal transmission efficiency, this cable is an essential tool for professionals seeking to optimize diagnostic accuracy and reliability in the automotive field.
