High Precision Fin Press Punching Machine Automatic Production Line1
3 month ago
- Overview
- Product Description
- Detailed Photos
- Company Profile
- FAQ
Basic Info.
Product Description
A. Main functions and features:
1. CB series closed type fin press is a special production line for fin production in the refrigeration industry, consisting of high-speed precision punching, discharging rack, oil lubrication tank, pulling device (single and double-jump), suction rack, collector, electrical system , pneumatic system composition.2. The mainframe speed control adopts frequency conversion control
3. The host has a hydraulic overload function
4. Using a quick die change device
5. Adopt human-machine interface and PLC and rotary encoder electrical centralized control system to ensure the reliable execution of various functions of the automatic production line.
B. Key parameters,
| No. | Names | Unit | Specifications | ||
| CB63 | CB85 | CB100 | |||
| 1 | Nominal Pressure | KN | 630 | 850 | 1000 |
| 2 | Stroke of slide | mm | 40-60 | 40-60 | 40-60 |
| 3 | Stamping Strokes | SPM | 150-300 | 150-300 | 150-300 |
| 4 | Die set height | mm | 250-300 | 250-300 | 270-320 |
| 5 | Die height adjustment | mm | 80 | 80 | 80 |
| 6 | Size of table(FB x LR) | mm | 900×1300 | ||
| 7 | Thickness of table | mm | 80 | 90 | 100 |
| 8 | Distance from table to floor | mm | 720 | 760 | 760 |
| 9 | Bottom size of slide (FB x LR) | mm | 730×850 | ||
| 10 | Main motor (power) | KW | 7.5 | 11 | 15 |
| 11 | Air pressure | MPa | 0.5 | 0.5 | 0.5 |
| 12 | Collector length | mm | 1200/1500/2000 | 1200/1500/2000 | 1200/1500/2000 |
| 13 | Aluminum coils max.width | mm | 545 | 615 | 850 |
| 14 | Aluminum coils inner Dia. | mm | ∮75/∮150 | ∮75/∮150 | ∮75/∮150 |
| 15 | Aluminum coils outer Dia. | mm | ∮1000 | ∮1000 | ∮1000 |
C. key parts brands
we also could adjsut it at customer's needs
| NO. | Content | Manufacturer |
| 1 | Inverter | Inovance |
| 2 | PLC programmer | OMRON |
| 3 | HMI (color screen) | Taiwan Weinview |
| 4 | Rotary encoder | OMRON |
| 5 | Main pneumatic components | AirTAC |
| 6 | Main hydraulic components | YUKEN |
| 7 | Centralized lubrication | IHI |
| 8 | Dual valve of main clutch brake | TACO |
| 9 | Photoelectric safety device | Keli |
We, Ningbo Xin Chang Machinery Co.,Ltd are a professional designer and manufacturer in friction welding machine, resistance welding machine and Heat exchanger equipment. Our factory is in this line more than 20 years, we have more than 10 senior mechanical and electrical specialists and total more than 200 staff, our machine is famous in China. We have CCC, ISO9001 and CE certificates.
Over the years, we have exported so many machines to 30 and more countries, such as France,Spain,Poland,Russia,Indonesia,Vietnam,Pakistan,India,Mexico,Egypt etc.
Our main products are Heat exchanger equipment, Friction welding machine, spot welding machine, projection welding machine, butt welding machine, seam welding machine, multi head welding machine for wire mesh, and other various special welding machine for metal connection in different industries.
We always adhere to the management idea of "Integrity, profession, innovation, and win-win", to make Xin Chang becomes trustworthy enterprise of customers. Good product quality, perfect after-sales service, and professional technical support make customers choose no regrets and worry-free use.
