Product details

[FHG3000]

Built to Match Your Mold, Shot after Shot

The machine and the mold work as one system. The [FHG3000] is designed around that relationship, from clamping to plasticizing to configuration, so your mold performs consistently from the first shot to the last.

Machine and Mold Working Together

1. Clamping and Mold Locking

The strong clamping structure keeps the mold locked stably during injection, reducing flash and improving product consistency across every cycle.

2. Plasticizing for Your Material

Smooth plasticizing and accurate material control help the machine adapt to the plastic material used in your mold, supporting stable shot repeatability.

3. Shot Repeatability for Multi-Cavity Molds

Stable shot repeatability helps every cavity fill consistently, which supports dimensional accuracy and production consistency in multi-cavity tooling.

4. Configuration around Your Mold

Machine configuration can be adapted to mold size and cavity number, together with product weight, plastic material, and production capacity requirements.

5. Mold Support from FUHONG

FUHONG provides mold support and matching suggestions as part of the complete plastic processing solution, covering machine selection, mold matching, production support, and after-sales service.

Application Range

Household plastic products
Bottle caps and packaging components
Industrial plastic parts
Electrical appliance parts
Automotive plastic components
Plastic containers and fittings
Commodity plastic products
Customized injection molded parts

Engineering Support

Over 20 years of experience in injection molding machinery and mold manufacturing
Complete plastic processing solutions including mold support, auxiliary equipment suggestions, production line matching, and technical guidance
Global supply with machine selection, configuration advice, installation guidance, operation training, and after-sales service
Practical, durable, and cost-effective equipment built for long-term production value

Technical Specifications

Please add the actual parameters of each product model to this section.

ITEM		UNIT	FHG3000
Injection Unit	Screw Diameter	mm	55	60	65
	Screw L/D Ratio	L/D	22.9	21	19.4
	Shot Volume(Theoretical)	cm3	665	792	928
	Shot Weight(PS)	g	605	720	845
	Injection Rate	g/s	140	173	203
	Injection Pressure	Mpa	233	196	167
	Screw Speed	r/min	0-180
Clamping Unit	Clamping Force	KN	3000
	Toggle Stroke	mm	610
	Max. Mould Height	mm	620
	Min. Mould Height	mm	250
	Space Between Tie-Bars	mm	620×620
	Ejector Force	KN	70
	Ejector Stroke	mm	150
Others	Max. Pump Pressure	Mpa	16
	Pump Motor Power	KW	37
	Heater Power	KW	18.3
	Machine Dimension(LWH)	m	6.11×1.77×2.20
	Machine Weight	Ton	8.7
	Oil Tank Capacity	L	300
