DPDT IP68 Waterproof and Toggle Switch Solder Terminal with Yellow Handle Sets
4 month ago
Product details
As a professional toggle switches manufacturer based in China, we offer toggle switches covering diverse models including standard Toggle Switch On Off and IP68 Toggle Switch. When performance, durability, and reliability matter most, our YESWITCH HT802 Series Toggle Switch, also a premium High Current Toggle Switch, delivers industrial-grade control for heavy-duty applications. Engineered with IP68 highest waterproof and dustproof protection, dual-circuit ON-OFF-ON switching, and solder terminal flat base design, this switch is built to withstand harsh conditions while maintaining precise, consistent operation.
Notable Features Double Poles Toggle Switch
IP68 Waterproof & Dustproof – Unmatched Environmental Resistance
Featuring a fully sealed, rugged construction, this toggle switch meets IP68 ingress protection standards, making it impervious to water immersion, heavy rain, mud, oil, dust, and high humidity. Whether installed on heavy vehicles, outdoor machinery, or marine equipment, it remains fully functional even in the toughest working environments. The yellow protective rubber boot provides a tight, flexible seal around the toggle, enhancing durability and preventing accidental operation. It ensures stable performance in temperatures ranging from -40°C to +85°C, ideal for year-round outdoor and marine use.
Dual Circuit ON-OFF-ON – Versatile & Efficient Control
Designed with double-pole, double-throw (DPDT) circuitry, this switch offers three stable operating positions: ON – OFF – ON. It can independently control two separate circuits, supporting functions such as motor reversing, power selection, mode switching, and equipment adjustment. With high-precision internal contacts, the switch provides crisp, responsive actuation and secure positioning. It supports high-current load capacity, low contact resistance, and stable conductivity for long-term industrial use.
Solder Terminals with Flat Base – Easy Installation & Secure Mounting
The switch features a flat base structure and solder-style terminals for strong, vibration-resistant connections. This design ensures stable installation on control panels, prevents loosening during machine operation, and fits standard mounting cutouts. Its low-profile, panel-flush design makes it suitable for control consoles in heavy-duty vehicles, construction machinery, ships, and outdoor waterproof equipment.
High-Visibility Yellow Boot – Safe & Ergonomic
The bright yellow protective boot stands out clearly on control panels, improving operational efficiency and reducing the risk of misoperation. The ergonomic toggle design delivers smooth, comfortable handling even with gloved hands.
Ideal Applications
- Heavy-duty trucks, engineering vehicles, and large automotive systems
- Outdoor waterproof machinery and industrial control equipment
- Marine and boating electronics, navigation systems, and deck controls
- Construction machinery such as excavators, aerial work platforms, and lift controllers
- Agricultural equipment, mining machinery, and harsh-environment electrical systems
Why Choose This Toggle Switch?
- IP68 fully waterproof and dustproof
- Dual-circuit ON-OFF-ON for versatile control
- Durable yellow rubber boot for extra protection
- Solder terminals + flat base for stable, vibration-proof installation
- Rugged build for long life in extreme environments
Equip your equipment with a control switch that performs as tough as your operations. Our IP68 Yellow Handle Toggle Switch brings reliability, safety, and precision to every critical application.
SPECIFICATIONS
- CONTACT RESISTANCE:20m ohm(Max)
- INSULATION RESISTANCE:100VDC-100M ohm(Min)
- DIELECTRIC STRENGTH:1500VAC-1MINUTE
- MECHANICAL LIFE CYCLE:100.000 CYCLES
- OPERATING TEMPERATURE:-40 to +85 DEGREES
- FRONT SEAL:IP68
RATING
- RESISTIVE LOAD:16A 125/250VAC,15A 28VDC
- INDUCTIVE LOAD:15A 28VDC
MATERIAL
- ACTUATOR:COPPER ALLOY
- HOUSING:NYLON (UL94V-0)
- BUSHING:ZINC ALLOY
- TERMINAL:COPPER ALLOY
- CONTACT:COPPER ALLOY
- O-RING:SILICONE RUBBER
- SHEEL:STAINLESS STELL
