- Vibrant Yellow Handle with Sleeve Design: High visibility, easy operation, waterproof toggle switch and comfortable grip, enabling quick identification and switching even in complex working conditions.
- Screw-Convex Base Terminals: Secure wiring, simple installation, and reliable electrical connections that resist loosening over time.
- IP68 Maximum Protection Rating: Fully dustproof and waterproof, ideal for harsh environments such as humidity, dust, oil, and outdoor applications.
- Two-Position (ON)-OFF-(ON) Switching: Flexible control for circuit activation, deactivation, and directional switching to meet diverse operational needs.
- High Load Capacity: Supports heavy-duty currents up to 16A 125/250VAC and 15A 28VDC, suitable for motors, power supplies, lighting, and various load devices.
- Wide-Range Applications: Perfect for industrial control panels, engineering machinery, marine equipment, outdoor power systems, communication base stations, agricultural machinery, and automated production lines,professional Toggle switches manufacturer is located in China.
Competitive Merits Sealed Power 15A 250VAC Toggle
1. Robust Construction: Built to Last
The screw-convex base not only enhances terminal reliability but also improves overall vibration resistance and mechanical strength. Paired with a high-quality flame-retardant housing, it ensures outstanding performance even in high-temperature and high-humidity conditions
- Strong load capacity for stable, long-term handling of high currents.
- Low contact resistance ensures excellent conductivity and minimizes energy loss.
- Two-position (ON)-OFF-(ON) design includes a central "OFF" position for added operational safety
3. Environmental Adaptability: Ready for Any Challenge
With an IP68 rating, this switch can withstand immersion in 1.5 meters of water for 30 minutes without performance loss, making it ideal for outdoor equipment, marine applications, cleaning systems, and food processing environments.
- Industrial Automation: Control cabinets, PLC peripheral devices, motor start/stop switching.
- Transportation & Marine: Control panels, navigation lights, pump control systems.
- Energy Equipment: Generator controls, PV inverters, distribution boxes.
- Outdoor & Special Equipment: Construction machinery, agricultural irrigation systems, outdoor lighting control.
- Telecom Infrastructure: Base station power switching, backup circuit control.
- CONTACT RESISTANCE:20m ohm(Max)
- INSULATION RESISTANCE:100VDC-100M ohm(Min)
- DIELECTRIC STRENGTH:1500VAC-1MINUTE
- MECHANICAL LIFE CYCLE:100.000 CYCLES
- OPERATING TEMPERATURE:-40 to +85 DEGREES
- FRONT SEAL:IP68
- RESISTIVE LOAD:16A 125/250VAC,15A 28VDC
- INDUCTIVE LOAD:15A 28VDC
- ACTUATOR:COPPER ALLOY
- HOUSING:NYLON (UL94V-0)
- BUSHING:ZINC ALLOY
- TERMINAL:COPPER ALLOY
- CONTACT:COPPER ALLOY
- O-RING:SILICONE RUBBER
- SHEEL:STAINLESS STELL
