Plunger seat safety switches

3 week ago

2 0 

9 year

Product details

1. Manufacturer Introduction & Stable Electrical Performance

We are YESWITCH Electronics, one of China’s leading manufacturers and suppliers of Plunger Safety Switch, focusing on safety detection switches for garden and handling machinery. This seat detection switch adopts (ON)-OFF momentary function with standard 5A 24VDC rating. Strict electrical indicators are controlled: max 50mΩ contact resistance, minimum 100MΩ insulation resistance, and 10,000 dielectric cycles. It reaches 75,000 mechanical cycles, and works stably under -40℃~85℃ and 45%~85% humidity, fully adapting to outdoor all-weather operation.

2. Flame Retardant Material & Standard Mechanical Stroke Design

Our mature Momentary Plunger Seat Switches uses UL94V-0 black PP for both body and plunger, effectively resisting high temperature aging and outdoor mud corrosion. The operating pressure is fixed at 1600gf ±300gf with 9.5mm ±1.0 stroke, delivering clear pressing feedback when operators sit or leave the seat. Gold-plated brass terminals avoid oxidation and poor contact after long-term vibration, solving frequent circuit failure problems of ordinary low-cost Mower Plunger Safety Switch.

3. Wide Equipment Matching & Custom OEM Service

We supply complete Interlock Plunger Safety Switch For Mower Golf Cart Forklift Switch for global machinery OEM customers. This safety switch is widely installed on riding lawn mowers, golf carts and small forklifts to realize automatic power-off protection when no operator is seated. We support customized terminal types, wire harness and mounting size according to customer equipment design. All finished switches pass temperature cycling and life aging tests before delivery. Small trial orders and free samples are available to help buyers reduce after-sales maintenance cost and improve equipment safety standard.
