Product details

Product Overview

As a professional Stainless Steel Push Button Switch Manufacturer based in China, we proudly present the PYCA Series, a premium line of Small Metal Push Button Switch tailored for diverse industrial, marine, automotive and outdoor scenarios. As reliable Metal Switches, this series combines compact structure, outstanding sturdiness and excellent environmental adaptability. Engineered with premium materials and sophisticated sealing technology, it acts as a practical Waterproof Metal Push Button Switch that resists water, dust, vibration and impact effectively. It can operate stably under extreme temperatures and harsh working conditions, helping global clients cut equipment failure rates and long-term maintenance costs while boosting operational efficiency.

Product Features & Advantages

Excellent Waterproof & Anti-Dust Performance

Built with high-standard sealing structure, this Waterproof Metal Push Button Switch delivers superior water and dust resistance. It works perfectly in damp, dusty and splash-prone environments, which is a core advantage for marine equipment and outdoor machinery. The reliable sealing design prevents internal circuit damage caused by moisture and dust intrusion.

Anti-Vandal & Vibration-Resistant Design

Functioning as practical Anti-Vandal Switches, the PYCA Series adopts robust overall construction. It stands up to accidental collision, intentional damage and long-term mechanical vibration, maintaining stable performance even in unattended public facilities and heavy-duty industrial equipment. The optimized internal structure greatly reduces failure risks from external force.

Stable Electrical Performance & Ultra-Long Service Life

With maximum 50mΩ initial contact resistance and minimum 1GΩ insulation resistance at 500VDC, the switch ensures smooth circuit conduction and strong electric leakage prevention. It features 500,000 cycles of electrical life under full load and 1,000,000 cycles of mechanical life. The 10ms contact bounce guarantees sensitive and accurate signal transmission during frequent use.

Wide Temperature Adaptability

Capable of working continuously from -30°C to 85°C, the switch adapts to frigid northern regions and high-temperature outdoor workshops. Premium raw materials effectively avoid performance degradation or component aging under extreme temperatures.

Compact Size & Comfortable Operation

As a typical Small Metal Push Button Switch, it occupies little panel space and fits neatly into compact control panels, handheld controllers and mini dashboards. The 1.5mm total travel and 2N~5N operating force bring clear tactile feedback, enabling easy and precise operation for operators.

Diversified Installation & Strong Compatibility

Two types of bushings are optional. The standard model supports 0.5 Nm torque while the metal bushing type supports up to 1.5 Nm torque, meeting different installation and fastening demands. It supports soldering work at 350°C for 5 seconds, compatible with mainstream assembly processes of various manufacturers.

Application Scenarios

Our versatile Metal Switches serve a wide range of industries and devices, bringing tangible value to clients:

Marine Equipment: Ships, yachts and offshore working devices (resist seawater splash and salt corrosion)

Industrial Machinery: Factory automation equipment, engineering vehicles and mechanical control panels

Automotive Industry: Vehicle interior control parts, outdoor recreational vehicles and special-purpose cars

Public Facilities: Access control equipment, vending machines and public service devices (anti-vandal performance for long-term unattended use)

Outdoor Devices: Field detection instruments, garden machinery and all-weather outdoor electrical appliances

By adopting our switches, clients can lower parts replacement frequency, reduce equipment downtime and cut overall operational costs significantly.

Certifications and Compliance

All products of our company comply with international industry safety and environmental standards. The housing material is UL94v-0 flame retardant, with excellent fire resistance. Every batch of products has passed strict laboratory tests on dielectric strength, insulation performance and durability. We follow global environmental regulations, so our Stainless Steel Push Button Switch can be safely exported to Europe, America, Southeast Asia and other regions, fully meeting local market access requirements.

Customization Options

To satisfy personalized demands from global buyers, we provide comprehensive customized services:

Structural Customization: Customize bushing types, terminal styles and overall dimensions based on installation holes;

Appearance Customization: Adjust the color of button caps and print exclusive logos;

Parameter Customization: Optimize partial electrical parameters and operating force for special load requirements;

Function Customization: Match LED indicator lights and adjust circuit modes as requested.

Production Process & Quality Control

As a trusted China Metal Switches supplier, we implement full-process quality management:

Raw Material Inspection: Strict sampling test for DAP housing, polyamide cap and other raw materials to eliminate defective parts at the source;

Precision Processing: Adopt automated production equipment for component processing and assembly to guarantee consistent product accuracy;

Finished Product Testing: 100% testing on contact resistance, dielectric strength, waterproof performance and mechanical life;

Pre-Delivery Re-Inspection: Random inspection for packaged products to ensure all goods meet specifications before shipment.

FAQ

Q: What are the differences between the standard type and metal bushing type?

A: The metal bushing type has higher dielectric strength (1,500 VAC rms) and maximum torque (1.5 Nm), as well as larger current and voltage ratings, suitable for heavy-load and high-torque installation scenarios.

Q: Can this switch be used in long-term wet marine environments?

A: Yes. Thanks to professional waterproof structure and anti-corrosion materials, this Waterproof Metal Push Button Switch works reliably in marine and wet outdoor environments.

Q: What is the service life of the switch?

A: It has 500,000 cycles of electrical life under full load and 1,000,000 cycles of mechanical life, supporting long-term frequent operation.

Q: Do you accept customized products? What is the lead time?

A: We support multiple customization solutions. The regular lead time for customized orders is 7-15 working days, subject to order quantity and customization content.

Q: What is the maximum soldering temperature the switch can withstand?

A: The maximum soldering temperature is 350°C, and the sustainable soldering time is 5 seconds, which fits most conventional soldering processes.
