toggle switch
4 year ago
We are a professional Toggle Switches manufacturer from China, specializing in high‑performance control switches for industrial and outdoor use. Our HT802 Series Toggle switches cover Toggle Switch On Off and High Current Toggle Switch versions with IP68 protection for reliable operation in harsh environments. We provide stable quality, competitive pricing, and flexible customization to meet global buyer demands for automotive, marine, industrial machinery, and outdoor equipment.
Specification
- MECHANICAL LIFE: 40, 000 make-and-break cycles.
- CONTACT RATING: 0.4 VA max. @ 20 V AC or DC max.
- CONTACT RESISTANCE: Below 100 mΩ typ. initial@ 2-4 V DC, 100 mA.
- INSULATION RESISTANCE: 500 MΩ min.
- DIELECTRIC STRENGTH: 500 Vrms min.@ sea level.
- OPERATING TEMPERATURE: -30°C to 85°C.
Materials
- HOUSING AND BASE: Glass filled nylon 6/6 or 4/6, flame retardant, heat stabilized (UL94V-0).
- ACTUATOR: Glass filled nylon 6/6, flame retardant, heat stabilized (UL94V-0), with standard internal o-ring seal.
- SWITCH SUPPORT: Steel, with Sn plated.
- CONTACT: Phosphor bronze, Gold plated.
- TERMINALS: Brass, Gold plated.
Applications
- Telecommunication, Instrumentation, Medical equipment, Networking equipment and Handheld devices.
