5T wheel loader
2 year ago
| Description | Specification |
| rated load(kg) | 5000 |
| Rated bucket capacity(m³) | 3 |
| operating weight(kg) | 16300 |
| Max.breakout force(kN) | 150 |
| Max.dump height(MM) | 3400 |
| Max.dump reach(MM) | 1083 |
| Articulation angle(°) | ±35 |
| Climb ability(°) | 29 |
| Raising time(s) | ≤6 |
| Total cycle time(lifting, dumping, lowering)(s) | ≤10 |
| Min turning radius(MM) | 6200 |
| Wheel base(MM) | 2920 |
| Tread(MM) | 2250 |
| Min.ground clearance(MM) | 534 |
| Overall dimensions (l×w×h)mm(MM) | 7929×3024×3423 |
| travel speed(km/h) | |
| Forward gear I | 0~13.5 |
| II | 0~35 |
| reverse gear I | 0~17 |
| II | 0~38 |
| Engine Model | WD10G220E21 |
| Type | Water injection four-stroke inline |
| Rated power(kW) | 162 |
| Rated speed(rpm) | 2200 |
| Tire model | 23.5-25 |
| Steering system pressure(MPa) | 16 |
| The braking system | |
| Service brake | Gas-liquid caliper disc brake |
| Parking brake | Breathe manipulating drum brake |
| Fuel Tank | 260L |
| Engine Oil | 201L |
| Cooling System | 45L |
| Hydraulic System | 270L |
| Transmission and Torque Converter | 45L |
| Axles, Each | 27*2L |
2. Wider vision cabin, air conditioner will be optional,offer a comfortable riding environment.
3.Other option air condtioner, joystick/ quick/ hitch, weight scale, auto greasereverse cameralog grapplegrass grapple.
Packing & Delivery
Container 40HC 1 units can be installed
1.Standard packing, the machine body is without packing, but the machine will be well fastened and fixed in the container by wire rope.
