Chain Link Fence – Diamond Mesh Cyclone Fence for Perimeter Security & Sports Fields
Galvanized | PVC Coated | Stainless Steel | Woven Diamond Pattern
ISO 9001:2015Hot-Dip GalvanizedPVC Coated1"-4" MeshFactory Direct
ANJIA Group (Hebei Conquer Hardware Wire Mesh Co., Ltd.) manufactures high-quality chain link fence (also known as diamond fence or cyclone fence) using high-tensile mild steel wire. Woven in a diamond pattern, the fence is flexible yet strong. Available in electro-galvanized, hot-dip galvanized, PVC coated (green, black, white), and stainless steel 304/316. Excellent corrosion protection for long-term outdoor use. Widely used for residential perimeters, sports fields (tennis courts, baseball parks), roads, industrial sites, and public facilities.
Standard mesh openings: 1", 1.5", 2", 2.5", 3", 4" (25–100mm). Wire diameters: 1.2mm – 5.0mm. Roll heights: 0.6m – 3.0m. Roll lengths: 10m – 50m. Complete accessories: posts, tension bars, bands, ties, gates. Custom sizes and colors available for OEM orders.
Technical Specifications
| Parameter |
Specification |
| Material Base |
Mild steel wire (Q195), stainless steel 304/316 |
| Wire Diameter (Standard) |
1.2mm – 5.0mm (BWG 18# – 7#) |
| Mesh Opening (Diamond) |
1", 1.5", 2", 2.5", 3", 4" (25–100mm) |
| Roll Height |
0.6m – 3.0m (custom up to 4.0m) |
| Roll Length |
10m – 50m (custom up to 100m) |
| Surface Finish |
Electro-galvanized, hot-dip galvanized (≥40g/m²), PVC coated (green/black/white), stainless steel |
| Classification |
Electro galvanized, hot-dipped galvanized, PVC coated, stainless steel |
| Packing |
Roll ends wrapped with plastic woven bag, or as customer requirement |
| Accessories |
Steel posts, tension bars, tension bands, tie wires, gates |
| Lead Time |
10-15 days (standard), 15-20 days (custom) |
| Standards |
ISO 9001:2015, ASTM A641, BS 1722 |
*Custom mesh openings, wire diameters, and roll dimensions available. Mill test certificates provided.
Key Advantages
Flexible & Strong
Woven diamond pattern, easy to install
Corrosion Resistant
HDG or PVC coating for long life
Excellent Visibility
Open mesh maintains view
Complete System
Posts, fittings, gates available
Applications
Residential
Backyards, gardens, swimming pools
Sports Fields
Tennis courts, soccer fields, baseball parks
Roads & Highways
Boundary protection, safety barriers
Industrial
Warehouses, factories, airports
Agricultural
Farm perimeters, livestock enclosures
Why ANJIA Group?
30+ Years
Since 1996, 72k sqm ISO facility
Full Automation
Auto weaving & coating lines
Local Support
Kenya warehouse, Brazil partners
Custom Service
Any size, mesh, color
Exported to 80+ countries. Mill certificates & SGS/BV inspection available.
HEBEI CONQUER HARDWARE WIRE MESH CO., LTD. – Part of ANJIA Group China, Since 1996. Your Global Partner in Wire Mesh & Fencing.
FAQ
Q1: What is the difference between chain link and welded wire fence?
A: Chain link is woven (flexible, diamond pattern), easier to install on uneven ground. Welded wire is rigid (square pattern), stronger but less flexible. Both are available from ANJIA.
Q2: Which coating lasts longest outdoors?
A: Hot-dipped galvanized (≥40g/m²) or PVC coated provides 15-25 years of corrosion protection. Stainless steel offers 30+ years.
Q3: Can you supply custom roll heights and lengths?
A: Yes, any height from 0.6m to 4.0m, any length up to 100m. Minimum order quantity applies.
Q4: What accessories do I need for installation?
A: Steel posts (line posts, corner posts, gate posts), tension bars, tension bands, tie wires, and gates. We supply complete accessory kits.
Professional chain link fence supplier for contractors, wholesalers & importers
Free samples | Mill test certificates
Get Quote for Container Load – Direct from China Factory
ANJIA offers chain link fence in all standard sizes. Galvanized, PVC coated, stainless steel. Complete accessories available. 10-15 day lead time.
