Corrugated Sheet Cardboard Conveyor Automatic Stacker
Duplex Auto Basket Stacker for High Speed Corrugated Cardboard Production Line
-MAX Stacking Height: 1.8 m
*The machine can be converted into oil hydraulic driving through device addition: the driving of the lifting platform and feed-out rollers can be changed into oil hydraulic type
|
Paper Width(mm)
|
External Dimensions (mm) L*W*H
|
Weight(T)
|
Total Power of Motor(kW)
|
|
1400
|
18500*3800*3500
|
9
|
30
|
|
1600
|
18500*4000*3500
|
10
|
30
|
|
1800
|
18500*4200*3500
|
11
|
35
|
|
2000
|
18500*4400*3500
|
12
|
35
|
|
2200
|
18500*4600*3500
|
13
|
39
|
|
2300
|
18500*4700*3500
|
14
|
39
|
The conveyance device is divided into four sections to carry out accurate separation of cardboards by order/lot and make the cardboard stack more neatly.
1. The feed-out rollers are driven by a frequency converter controlled frequency conversion motor, so the acceleration and
deceleration are stable, the cardboard output is smooth, and it is not easy to make the cardboard turnover.
2. The lifting platform is driven by a frequency converter controlled brake motor and gravity counterweights are installed, so the acceleration and deceleration are stable and forceful and the speed changeover is reasonable and effective; thus, the cardboard stacking is smoother, the folded marks on cardboard are avoided and the life of the machine is extended.
3. The feed-out rollers are arranged closely and are lifted together with the lifting platform to reduce waste paper sheets.
4. The sun gear for paper output is pneumatically controlled and the air circuit is specially designed, so the paper output is
stable and tidy.
5. The ascending arc of the conveyance platform is reasonable, so partial lifting, etc. of the cardboard will not occur during
conveyance.
The production line was running smoothly with the help of the Automatic Stacker, which efficiently stacked the finished products. The Automatic Paper Stacker and Automatic Sheet Stacker were also working in sync to ensure all materials were organized and ready for packaging. In addition, the Corrugated Cardboard Stacker was busy stacking the cardboard sheets neatly for easy transportation. Overall, the stackers played a crucial role in streamlining the production process and increasing efficiency.
FAQ
2. Q: Why choose LLY PACK?
1). 22 Years of Specialization in Corrugated Industry Solutions that delight
2). Over 3500+ successful installation corrugated cardboard production line
3). Strict inspection before delivery
4). The unique company who drafts the latest version of national industry standard for corrugated machines in China
3. Q: How about the after-sale service?
All-round after-sales Service System
Engineers team provides solutions in the field of Mechanic/ Electric/ Operation.
TM online for 24 hours.
Online Quick Responsive service: Email, skype, MSN, Facebook, Linkin, Whatsapp, Instangram.
Our corrugated machine and corrugating roll have been exporting to over 40 countries, including: Vietnam, Thailand, Myanmar,Philippine, Malaysia, Indonesia, India, Egypt, Emirate, Bahrain, Saudi Arabic, Israel, Russia, Lithuania, Mexico, Brazil,Argentina, Venezuela, Honduras, Korea and etc.
