AH slurry pump

AHF Froth pump are designed to handle heavy froth. A large oversized inlet with a unique impeller inducer blade handles heavy froth and higher viscosity dense slurries with ease. The horizontal froth pumps has proven valuable for very dense slurries where viscosity starts to become a pumping issue for the standard slurry pumps.

Design Features of AHF Froth pump:
• Heavy duty construction with through-bolt design provides ease of maintenance and less down time.
• Ductile iron fully lined casing provides durability, strength and long service life.
• Large diameter, slow turning, high efficiency impellers maximize wear life and lower TOC.
• Large, open internal passages reduce internal velocities maximizing wear life resulting in lower operating costs.
• Unique impeller design for most difficult froth applications.
• Thick elastomer or metal bolt-in liners provide superior corrosion resistance plus offer ease of liner change-out and inter mixability to reduce over all maintenance costs and maximize wear life.
• Minimal shaft/impeller overhang reduces shaft deflection and increases packing life.
• Cartridge-style bearing assembly allows for maintenance in a clean environment without removal of the pump, resulting in reliable operation and prolonged bearing life.
• Standard TH can be converted by replacing cover plate, throat bush and impeller.
• Full flush, low flow or dry running centrifugal seals minimize water usage and operating costs.

EAHF4056QU1A05 impeller is used for 4D-AHF or 4E-AHF Froth pump

AHF Froth Slurry Pumps and Parts Manufacturer, CAHF2056QU1A05, DAHF3056QU1A05, EAHF4056QU1A05
FAHF6056QU1A05, FAHF8056QU1A05, STAHF10056QU1A05 for 2C-AHF, 3D-AHF, 4E-AHF, 6F-AHF, 8F-AHF,10ST-AHF froth slurry pumps
