500 kph pvc mixing and pelletizing line- short
2 year ago
Description：
PE/PP Water Ring Granulation Line - Advanced Plastic Recycling Solution
High-Efficiency Plastic Granulation System for PP/PE Waste
Our innovative water ring granulation line represents the next generation of plastic recycling technology, specifically engineered for processing:
PP/PE films (LDPE, LLDPE, HDPE)
Woven bags and raffia
Non-woven fabrics and industrial scraps
Post-industrial plastic waste
Core Features：
✔ Integrated Metal Detection - Automatic removal of metallic contaminants
✔ Forced Feeding System - Ensures consistent material flow and processing stability
✔ Water Ring Granulation - Produces uniform, high-quality pellets
✔ Vacuum Exhaust - Eliminates volatiles for superior pellet quality
Performance Benefits：
30% Higher Output compared to conventional granulators
Energy-Saving Design reduces power consumption by up to 25%
Low-Noise Operation (<75dB) for improved working environment
Stable Continuous Production with minimal downtime
Complete Processing Workflow：
Automatic Feeding→→→Pre-crushed material enters through forced feeder
→→→Metal detector removes ferrous/non-ferrous contaminants
→→→Extrusion & Filtration
→→→Twin-screw extruder with precise temperature control
→→→High-pressure filtration removes microscopic impurities
→→→Water Ring Pelletizing
→→→Cutting chamber with adjustable blade configuration
→→→Water-cooled pellets for perfect spherical shape
→→→Dehydration & Drying
→→→Centrifugal dewatering removes surface moisture
→→→Vibrating fluid bed dryer for complete moisture elimination
→→→Automated Packaging
→→→Sieving and grading system
→→→Bulk storage or bagging options
Complete Plastic Recycling Solutions
We provide end-to-end systems including:
Pre-washing and separation units
High-speed crushers and shredders
Water treatment and recycling systems
Material handling and storage solutions
|
model |
screw speed( r/min) |
host power (Kw) |
heating power(Kw) |
wind send motor power(Kw) |
cutting motor power(Kw) |
production capacity(Kg/h) |
cutter diameter |
granulation size(mm) |
center high(mm) |
|
SJSZ51/105 |
5-40 |
18.5 |
15 |
2.2 |
1.1 |
120-180 |
200 |
3×3 |
1000 |
|
SJSZ55/110 |
5-38 |
22 |
18 |
2.2 |
1.1 |
150-200 |
200 |
3×3 |
1000 |
|
SJSZ65/132 |
5-36 |
37 |
24 |
3 |
1.5 |
150-250 |
250 |
4×4 |
1000 |
|
SJSZ80/156 |
5-34 |
55 |
36 |
|
2.2 |
250-450 |
280 |
4×4 |
1000 |
|
SJSZ92/188 |
5-33 |
90 |
87 |
4 |
2.2 |
500-700 |
320 |
5x4 |
1000 |
