55-inch four-sided infrared touch all-in-one
11 month ago
Product details
Product Description:
Screen parameters: Screen size is 55 inches, LED backlight technology, display ratio is 16:9, resolution is 1920×1080 (supports higher resolution customization), brightness ≥400cd/m², contrast ≥1000:1, viewing angle is 178° (horizontal/vertical), ensuring clear and consistent visual effects at different viewing angles.
Touch parameters: Four-sided infrared touch technology, touch points support 10 points or more simultaneous touch, touch accuracy ±2mm, response time <5ms, can achieve accurate and fast touch operation, meet the needs of multiple people interacting at the same time.
Hardware parameters: The processor uses [specific model] high-performance chip, memory [X] GB, storage capacity [X] GB (expandable on demand), and the operating system supports mainstream systems such as Windows and Android, ensuring smooth system operation and meeting the software usage needs of different users.
Interface parameters: Equipped with [X] HDMI interfaces, [X] USB interfaces (USB 2.0 and USB 3.0 can be selected as needed), [X] VGA interfaces, [X] RJ45 network interfaces, and audio input and output interfaces. The rich interfaces can meet the connection requirements of various external devices and achieve high-speed data transmission and sharing.
Appearance and installation parameters: The appearance size of the all-in-one machine is [length × width × thickness] mm. The body material is a combination of high-strength metal and high-quality plastic, which is sturdy and durable with good heat dissipation performance. It can support wall mounting (the wall mounting hole spacing meets the VESA standard) and floor stand mounting, which is convenient for flexible installation and use in different places.
Touch parameters: Four-sided infrared touch technology, touch points support 10 points or more simultaneous touch, touch accuracy ±2mm, response time <5ms, can achieve accurate and fast touch operation, meet the needs of multiple people interacting at the same time.
Hardware parameters: The processor uses [specific model] high-performance chip, memory [X] GB, storage capacity [X] GB (expandable on demand), and the operating system supports mainstream systems such as Windows and Android, ensuring smooth system operation and meeting the software usage needs of different users.
Interface parameters: Equipped with [X] HDMI interfaces, [X] USB interfaces (USB 2.0 and USB 3.0 can be selected as needed), [X] VGA interfaces, [X] RJ45 network interfaces, and audio input and output interfaces. The rich interfaces can meet the connection requirements of various external devices and achieve high-speed data transmission and sharing.
Appearance and installation parameters: The appearance size of the all-in-one machine is [length × width × thickness] mm. The body material is a combination of high-strength metal and high-quality plastic, which is sturdy and durable with good heat dissipation performance. It can support wall mounting (the wall mounting hole spacing meets the VESA standard) and floor stand mounting, which is convenient for flexible installation and use in different places.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.
| Product Parameter | |
| Panel type | Original A + level commercial LCD panel |
| display resolution | 1920*1080 |
| Panel size | 55-inch (16:9) |
| Backlit type | E-LED |
| Valid display area | 1210*681 |
| Color degree | 8bit，1.07B |
| Luminance | 300-350 cd/㎡ |
| Contrast ratio | 1200：1（Typ.） |
| Visual Angle | 178°（H ）/178°(V) |
| Backlight life | For> 35,000 hours each |
| Horn | 2Ω×4&; 10W |
| HDMI-OUT | 1 |
| VGA-OUT | 1 |
| RG45-IN | 1 |
| USB3.0 | 2 |
| USB2.0 | 2 |
| Audio output | 1 |
| Headphone input | 1 |
| The 220v socket interface | 1 |
| WIFI | 1 |
| Touch parameters | |
| Touch-embedded mode | Built-in one-piece |
| The way of writing | Finger, touch pen, or other> 2.5mm |
| Number of touch points | At 10 o'clock |
| Touch resolution | 32767*32767 |
| Touch precision | ±1mm |
| Single refers to the response speed | ＜8ms |
| Minimum identification point diameter | 2.5mm (support 2.8mm double fine pen full screen writing) |
| Touch number | The theoretical number is infinite |
| Drivers | System automatic identification, no drive |
| Support system | windows7/10，Android，Mac OS |
| working temperature | -10~+50 ℃ |
| Computer parameters | |
| Motherboard | Industrial industrial control motherboard |
| CPU | The Intel-i5-4200M cpu is optional |
| Internal storage | The Ddr 3-4G is optional |
| Hard disk | The SSd-128G is optional |
| WiFi | 2.4G/5G |
| Body material | Aluminum alloy drawing wire oxidation face frame treatment process |
| Front frame glass | Physical tempered grade 7 explosion-proof glass |
| Appearance size of the whole machine | 1267.8 * 728.6 * 61.7 (excluding wall hanging) |
| The power of the machine | ≤100W |
| Standby power | ≤0.5W |
| Sound horn | Stereo sound effects, 2 * 10W high and height sound |
| Input voltage | 100~240V 50/60Hz |
| Service environment | Temperature-20℃ ~60℃ / humidity 10% RH ~ 90% RH |
| Storage environment | Temperature-10℃ ~55℃ / humidity 10% RH ~ 90% RH |
| packing measurement (mm) | |
| Product weight | |
| way to install | Wall hanging, with the base of the horizontal type, etc |
| Packaging accessories | power line |
| telecontroller | |
| WiFi antenna | |
| Wall hanging bracket | |
| Certificate |
