Doctor blades
3 year ago
LLY PACK(foshan) Co.,Ltd.
3 year
Product details
|
Line NO.(lpi)
|
Line NO. (I/CM)
|
Product
|
Bevel
|
Thickness(BSM)
|
Thickness (MM)
|
|
<180
|
<70
|
Durapoint
|
45°/90°
|
multi choices
|
multi choices
|
|
UHMW
|
45°/90°
|
multi choices
|
multi choices
|
||
|
180-280
|
70-110
|
DuraPoint
|
30°
|
multi choices
|
multi choices
|
|
UHMW
|
30°
|
multi choices
|
multi choices
|
||
|
>280
|
>110
|
Graphix
|
22°
|
0.0207.028"
|
0.5mm/0.71mm
|
|
ProFlex
|
22°
|
0.035"
|
0.9mm
|
||
|
Ink seal
|
Ink seal
|
UHMW
|
90°/45°
|
0.030"
|
0.8mm
|
|
Ink seal
|
Ink seal
|
Plasteel
|
22°
|
0.030"
|
0.8mm
|
Plastic UV Coating Doctor Blade for Flexo Gravure Printing Machine
Various specifications & Large Inventory & Fast Dispatch
Printing Machine Spare Parts-Doctor blades
Trupoint plastic ink scraper Flexo Printing Machinery Doctor Blade
1. TruPointTM doctor blades are an economical and practical substitute for steel doctor blades in flexographic printing and offset coating applications.
2. Last up to five times longer than steel and will effectively meter all types of inks and coatings.
3. Reduce anilox roll scoring and are safer to handle than steel
4. Maximize print quality and minimize costs
2. Last up to five times longer than steel and will effectively meter all types of inks and coatings.
3. Reduce anilox roll scoring and are safer to handle than steel
4. Maximize print quality and minimize costs
Suitable for Printing machines like Dongfang, Topra, Taiyi, Nantai, Keshenglong, Shinko, Dinglong and etc
Products Description
Application of Doctor Blade
Used in printing machine to scrape off excess ink on the surface of the roller, suitable for gravure printing machine, flexographic printing machine, pad printing machine, coating machine, packaging color printing, etc.
Types & Shape
Standard doctor blade :
Suitable for gravure, flexo printing machine, adopt imported high carbon steel, straightness, flatness, maintain the same to the size of plate roll, no knife line, scraping clean, economical and practical, have high efficiency. Hardness : 580-600HV.
Blue steel doctor blade :
Suitable for the use of corrosive/acidic ink, glue printing, play a certain anti-rust, anti- corrosion function. 580-600HV
Stainless steel doctor blade :
Suitable for water-based ink, and UV ink. For corrosive/acidic ink, glue printing plays a very good anti-rust anti-corrosion function, wear resistance and excellent toughness. 580-600HV.
Common Size （100m/box）
20*0.15mm
30*0.2mm
40*0.2mm
45*0.3mm
50*0.5mm
20*0.2mm
30*0.3mm
40*0.25mm
50*0.15mm
60*0.15mm
25*0.15mm
30*0.5mm
40*0.3mm
50*0.2mm
60*0.2mm
25*0.2mm
35*0.15mm
40*0.5mm
50*0.25mm
60*0.3mm
25*0.3mm
35*0.2mm
45*0.15mm
50*0.3mm
60*0.4mm
30*0.15mm
40*0.15mm
45*0.2mm
50*0.4mm
60*0.5mm
Ink scrapers are classified according to the material, carbon steel scrapers, stainless steel
scrapers, plastic scrapers, coated scrapers, requiring no notch on the surface of the knife edge, no impurities, smooth and
wear-resistant.
The speed of the printing machine can be divided into, high-speed machine (180 m/min), medium-speed machine (120 m/min), low-speed machine (80 m/min), generally according to the speed to select the corresponding material.The steel body material is vacuum heat treated to improve its tensile strength and blade hardness to extend the working life of the blade.
Machine speed
Material Choice
Country
＜100m / min
SK2
Japan
130-180m / min
C100
Germany
180-260m / min
20C
Switherland
