IP67 PUSHBUTTON SWITCH

12mm waterproof momentary engine start pushbutton round black plastic push button switch

Product Overview

We are an experienced Stainless Steel Push Button Switch Manufacturer based in China, devoting ourselves to developing and producing premium metal control switches for industrial machinery, outdoor facilities and commercial devices. This push button switch features a compact mounting size of Ø8.20mm, so it belongs to a typical Small Metal Push Button Switch. It combines dual operating modes (momentary and self-lock), full IP68 waterproof performance and customizable LED indicator lights. Crafted with multiple optional metal and engineering plastic materials, this series of products delivers stable running performance even under vibration, extreme temperature and humid conditions. For equipment manufacturers, wholesalers and maintenance suppliers, it is a cost-effective component that cuts long-term replacement costs and optimizes overall equipment stability.

Product Features & Advantages

1. Diversified Material Selection, Sturdy and Durable Structure

As reliable Metal Switches, this product provides three mainstream material solutions for key external parts including bushing and actuator: stainless steel, nickel plated brass and aluminum alloy. All metal materials feature high hardness, scratch resistance and corrosion resistance, which can withstand frequent collision and long-term vibration on working sites. The base and internal components adopt high-performance PBT, PC, POM and PA66 engineering plastics, which own excellent insulation and structural stability. Matched with high-elastic spring steel components, the switch will not have loose rebound or stuck buttons after years of use, far more durable than ordinary plastic switches.

2. IP68 Full Waterproof & Dustproof, Adapt to Harsh Working Conditions

Equipped with integrated silicone sealing structure and precision assembly technology, this IP68 Waterproof Push Button Switch reaches the highest IP68 protection standard. It can resist long-term water immersion, water splashing and dense dust accumulation. Whether installed on outdoor field machinery, marine equipment or wet industrial workshops, the internal circuit will not be eroded by moisture and dirt. The silicone sealing accessories maintain good flexibility in both low and high temperature environments, effectively avoiding common faults such as poor contact and button jamming caused by aging of sealing parts.

3. Excellent Electrical Performance, Safe and Stable Circuit Operation

The contact resistance of the product is strictly controlled below 50 mΩ, ensuring smooth transmission of weak current signals. The minimum insulation resistance is 100MΩ, and the dielectric strength is up to 1000 Vrms, which can effectively prevent electric leakage and circuit breakdown risks. Designed for 0.3A 12VDC weak current circuits, it fully meets the control requirements of various small-power equipment. The whole series has passed strict life tests: the mechanical life of momentary version is up to 200,000 cycles, and the self-lock version is 100,000 cycles; the electrical life under full load can reach 50,000 on-off actions, which fully adapts to the use demand of frequent switching.

4. Comfortable Operation & Wide Temperature Adaptability

The overall travel of the button is 3.0mm, with a standard operating pressure of 2.5±1N. The pressing feedback is clear and moderate, which will not cause fatigue even after long-time manual operation. The nut installation torque ranges from 5 to 14Nm, matching the installation specifications of most standard control panels, and the assembly and disassembly work is simple and labor-saving. The product can operate stably in the temperature range of -20°C to 85°C, covering cold outdoor areas and high-temperature equipment operation spaces, and can be used normally in most regions and complex working environments.

5. Rich LED Light Options, Practical Metal Light Design

This practical Metal Light Switch supports multiple LED voltages and six common lamp colors. Users can freely match red, yellow, orange, blue, green or white indicator lights according to equipment design and functional identification needs. Each type of lamp bead is equipped with matched current and voltage parameters to ensure stable light emission and long service life. The built-in indicator light can clearly display the operating status of the equipment, which not only optimizes the overall appearance of the equipment, but also helps operators quickly judge the running state of the machine and improve work efficiency.

6. Anti-Vandal Performance, Suitable for Public and Unattended Equipment

With reinforced metal shell and compact internal structure, this product can also be used as professional Anti-Vandal Switches. It can effectively resist artificial collision, deliberate damage and daily wear, and will not be easily damaged in public shared equipment and unattended industrial devices. Its compact size and solid structure make it the preferred matching part for many public facilities and outdoor unattended equipment.

Application Scenarios

This multi-functional metal push button switch has strong universality and is widely used in multiple industries, bringing tangible economic benefits to global buyers:

Industrial Automation Equipment: Control cabinets, machine tools, testing instruments and small power distribution devices on production lines;

Construction & Agricultural Machinery: Various control buttons on engineering vehicles, garden machinery and field operation equipment;

Outdoor & Marine Equipment: Outdoor monitoring equipment, landscape facilities, ships, yachts and other wet environment equipment;

Commercial & Public Facilities: Access control systems, vending machines, shared service equipment and public terminal devices.

Choosing our products can greatly reduce the frequency of parts replacement, cut unexpected equipment downtime, and help you reasonably control the overall operation and maintenance costs.

Certifications and Compliance

All products are produced and inspected in accordance with international electronic component safety standards. Every finished product will undergo comprehensive tests including electrical performance, waterproof grade, mechanical life and temperature resistance. As a professional manufacturer focusing on metal switches, our products comply with mainstream export regulations in Europe, America, Southeast Asia and other regions. We can provide complete test reports and qualification documents upon request to fully guarantee product compliance and use safety.
