45°elbow

11 month ago

12 0 

Gongyi xinhuafeng pipeline equipment co. LTD.

13 month

Product details

Classification of Elbows by Production Process and Curvature Radius

By Production Process: Welded elbows, stamped elbows, push-formed elbows, cast elbows, butt-welded elbows, etc.

By Curvature Radius: Long radius elbow (with a curvature radius equal to 1.5 times the outer diameter of the pipe, i.e., R=1.5D) and short radius elbow (with a curvature radius equal to the outer diameter of the pipe, i.e., R=1.0D).

Considerations for Selection and Installation of Elbows

When selecting and installing elbows, the following factors need to be considered:

1.Fluid Characteristics: Including flow velocity, flow rate, pressure, and temperature.

2.Pipeline System Requirements: Such as direction changes, reduction of resistance and pressure loss, and protection of pipelines and equipment.

3.Installation Location: Consideration should be given to the flow direction of the fluid, pressure loss, and coordination with other pipe fittings.

4.Connection Methods: Commonly used methods include welding, threaded connections, and flange connections. The appropriate connection method should be selected based on actual conditions.
